| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 7M-0326 |
CONNECTOR
|
1 | 1305 |
| 9H-3757 |
WASHER (0.516X1X0.094-IN THK)
|
2 | 1305 |
| 1S-7446 |
SCREW-MACHINE (8-32X0.437-IN)
|
3 | 1305 |
| 8C-9660 |
WASHER (4.6X7.9X0.8-MM THK)
|
3 | 1305 |
| 9S-2544 |
SCREW-HEX HEAD (8-32X11.13-MM)
|
9 | 1305 |
| 7M-0327 |
WASHER-THRUST (17.4X25.4X1.6-MM THK)
|
1 | 1305 |
| 3T-3418 |
FRAME AS-END
|
1 | 1305 |
| 3T-3423 |
CUP
|
1 | 1305 |
| 3T-3424 |
PLUG-FELT
|
1 | 1305 |
| 9G-4101 |
BUSHING-END
|
1 | 1305 |
| 3T-9525 |
PLATE AS-BRUSH (STARTING MOTOR)
|
1 | 1305 |
| 1T-0808 |
WASHER (0.516X0.812X0.09-IN THK)
|
2 | 1305 |
| 3T-3422 |
WIRE AS
|
1 | 1305 |
| 2J-8163 |
SEAL-O-RING
|
2 | 1305 |
| 7X-3373 |
BOLT (5/16-18X0.88-IN)
|
1 | 1305 |
| 3T-3434 |
PLUG
|
6 | 1305 |
| 5J-5314 |
BOLT (5/16-18X1.5-IN)
|
5 | 1305 |
| 3L-3380 |
BUSHING-TERMINAL
|
1 | 1305 |
| 8C-3089 |
SEAL-O-RING
|
1 | 1305 |
| 4M-1853 |
LEVER AS-SHIFT
|
1 | 1305 |
| 5M-3034 |
LOCKNUT (5/16-24-THD)
|
1 | 1305 |
| 7L-2894 |
GASKET
|
4 | 1305 |
| 4M-1831 |
PLUG-LEVER HOUSING
|
4 | 1305 |
| 4M-1854 |
SHAFT-LEVER
|
1 | 1305 |
| 1H-1023 |
SEAL-O-RING
|
1 | 1305 |
| 2D-6392 |
SEAL-O-RING
|
1 | 1305 |
| 7T-3974 |
HOUSING AS-DRIVE
|
1 | 1305 |
| 3T-5343 |
DRIVE AS-MOTOR
|
1 | 1305 |
| 2H-3429 |
RING-RETAINING
|
1 | 1305 |
| 6V-1322 |
BOLT (1/4-20X0.375-IN)
|
4 | 1305 |
| 8T-4205 |
WASHER-HARD (7.2X14.5X2-MM THK)
|
4 | 1305 |
| 6N-3279 |
INSULATOR
|
1 | 1305 |
| 0S-1597 |
BOLT (1/4-28X1-IN)
|
13 | 1305 |
| 1M-9971 |
SPACER (0.835X1.72X0.188-IN THK)
|
1 | 1305 |
| 1H-2629 |
STRIP-INSULATION
|
3 | 1305 |
| 7M-0324 |
COIL AS-FIELD
|
1 | 1305 |
| 3R-8797 |
SCREW & WASHER AS (3/8-24X0.72-IN)
|
12 | 1305 |
| 7F-3488 |
SHOE-POLE
|
6 | 1305 |
| 7M-8651 |
ARMATURE AS
|
1 | 1305 |
| 7M-0325 |
INSULATOR
|
1 | 1305 |
| 3T-9524 |
BRUSH AS
|
6 | 1305 |
| 3N-3763 |
KIT-TERMINAL (STARTING MOTOR) (INCLUDES BUSHINGS & WASHERS)
|
1 | 1305 |
| 338-3453 |
SOLENOID AS-STARTING MOTOR (24-VOLT)
|
1 | 1305 |
| 3R-8801 |
CLAMP
|
1 | 1305 |
| 8F-1434 |
LOCKWASHER
|
2 | 1305 |
| 6V-8188 |
NUT (1/2-13-THD)
|
6 | 1306 |
| 7X-0562 |
WASHER-HARD (13.5X19X0.8-MM THK)
|
6 | 1306 |
| 4B-2049 |
NUT (10-32-THD)
|
6 | 1306 |
| 8T-0328 |
WASHER-HARD (5.5X10X1-MM THK)
|
10 | 1306 |
| 3T-9494 |
SPRING
|
6 | 1306 |
