| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 187-1315 |
GASKET AS
|
1 | 46 |
| 273-3033 |
CYLINDER HEAD GP
|
1 | 46 |
| 2A-3746 |
PLUG-CUP
|
1 | 46 |
| 271-7442 |
PLUG
|
2 | 47 |
| 2A-4429 |
LOCK-RETAINER
|
48 | 47 |
| 163-2478 |
SEAL-VALVE STEM
|
24 | 47 |
| 183-3407 |
PLUG AS (EACH INCLUDES)
|
4 | 47 |
| 9S-8004 |
PLUG-O-RING
|
1 | 47 |
| 153-4906 |
SEAL-O-RING
|
1 | 47 |
| 188-3122 |
VALVE-EXHAUST
|
12 | 47 |
| 190-6115 |
SPRING-VALVE (INNER)
|
24 | 47 |
| 190-6117 |
SPRING-VALVE (OUTER)
|
24 | 47 |
| 211-2134 |
RETAINER
|
24 | 47 |
| 217-0609 |
SEAT-VALVE SPRING
|
12 | 47 |
| 255-4961 |
CYLINDER HEAD AS
|
1 | 47 |
| 260-4856 |
GUIDE-VALVE
|
24 | 47 |
| 203-3237 |
GUIDE-VALVE (0.13-MM OS OD)
|
1 | 47 |
| 203-3238 |
GUIDE-VALVE (0.5-MM OS OD)
|
1 | 47 |
| 148-8395 |
PLUG AS (EACH INCLUDES)
|
2 | 47 |
| 3K-0360 |
SEAL-O-RING
|
1 | 47 |
| 9S-8005 |
PLUG-O-RING
|
1 | 47 |
| 183-2317 |
SEAL-O-RING
|
2 | 47 |
| 8T-6764 |
PLUG-PIPE
|
2 | 47 |
| 319-6237 |
PLUG AS (EACH INCLUDES)
|
2 | 49 |
| 228-7096 |
SEAL-O-RING
|
1 | 49 |
| 271-7442 |
PLUG
|
1 | 49 |
| 2A-4429 |
LOCK-RETAINER
|
48 | 49 |
| 163-2478 |
SEAL-VALVE STEM
|
24 | 49 |
| 321-8638 |
PLUG AS (EACH INCLUDES)
|
4 | 49 |
| 214-7568 |
SEAL-O-RING
|
1 | 49 |
| 321-8635 |
PLUG
|
1 | 49 |
| 188-3122 |
VALVE-EXHAUST
|
12 | 49 |
| 190-6115 |
SPRING-VALVE (INNER)
|
24 | 49 |
| 190-6117 |
SPRING-VALVE (OUTER)
|
24 | 49 |
| 211-2134 |
RETAINER
|
24 | 49 |
| 217-0609 |
SEAT-VALVE SPRING
|
12 | 49 |
| 311-7228 |
CYLINDER HEAD AS
|
1 | 49 |
| 260-4856 |
GUIDE-VALVE
|
24 | 49 |
| 203-3237 |
GUIDE-VALVE (0.13-MM OS OD)
|
1 | 49 |
| 203-3238 |
GUIDE-VALVE (0.5-MM OS OD)
|
1 | 49 |
| 148-8395 |
PLUG AS (EACH INCLUDES)
|
2 | 49 |
| 3K-0360 |
SEAL-O-RING
|
1 | 49 |
| 9S-8005 |
PLUG-O-RING
|
1 | 49 |
| 8T-6764 |
PLUG-PIPE
|
2 | 49 |
