| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 372-7129 |
GENERATOR GP
|
1 | 447 |
| 144-9439 |
ROTOR GP-GENERATOR
|
1 | 523 |
| 2N-2030 |
FAN-VENT
|
1 | 523 |
| 4P-1798 |
DEFLECTOR-UPPER
|
1 | 523 |
| 4P-4532 |
DEFLECTOR-LOWER
|
1 | 523 |
| 7E-9592 |
COVER-DRIP
|
1 | 523 |
| 5P-0059 |
BOLT (5/16-18X6-IN)
|
4 | 523 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
|
17 | 523 |
| 5L-2087 |
SPACER (9.25X13.72X50.8-MM THK) BOLT (5/16-18X1.125-IN)
|
4 | 523 |
| 4B-3388 |
4B-3388
|
5 | 523 |
| 7E-3030 |
SPACER (8.3X11.9X16.1-MM THK)
|
1 | 523 |
| 108-6950 |
ROTOR-EXCITER
|
1 | 523 |
| 108-6949 |
STATOR-EXCITER
|
1 | 523 |
| 360-4434 |
BRACKET-BEARING
|
1 | 523 |
| 108-7822 |
RETAINER
|
2 | 523 |
| 5P-2955 |
BOLT (5/16-18X2.5-IN)
|
4 | 523 |
| 5P-0537 |
WASHER-HARD (7.2X14.5X2-MM THK) BOLT (1/4-20X1.75-IN)
|
4 | 523 |
| 1B-2713 |
1B-2713
|
4 | 523 |
| 4P-3153 |
SPACER (20.6X77X27.8-MM THK)
|
1 | 523 |
| 290-5564 |
HEAT SINK AS
|
1 | 523 |
| 234-5059 |
BUSHING BOLT (1/4-20X1.5-IN)
|
1 | 523 |
| 4M-5282 |
4M-5282
|
4 | 523 |
| 108-8265 |
SCREEN AS
|
2 | 523 |
| 1B-9575 |
BOLT (5/16-18X1.56-IN)
|
4 | 523 |
| 5M-6214 |
PLUG-PIPE
|
2 | 523 |
| 108-1468 |
PLATE-COUPLING
|
1 | 523 |
| 7L-5452 |
SHIM (0.8-MM THK)
|
2 | 523 |
| 9X-2119 |
BOLT-12 POINT HEAD (7/8-9X2.5-IN) WASHER-HARD (24X41.5X4-MM THK)
|
8 | 523 |
| 5P-8249 |
5P-8249
|
8 | 523 |
| 269-3993 |
STATOR AS (PERMANENT MAGNET)
|
1 | 523 |
| 108-5748 |
SLEEVE-SHAFT ROTOR (MAGNETIC)
|
1 | 523 |
| 108-5749 |
108-5749
|
1 | 523 |
| 194-5188 |
HEATER GP-SPACE
|
1 | 523 |
