| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 2D-4867 |
FITTING-GREASE (FAN DRIVE)
黄油嘴 |
1 | 187 |
| 4B-4550 |
FITTING-PRESSURE RELIEF (1/8-27 PTF)
|
1 | 187 |
| 5P-7979 |
BOLT-LOCKING (5/16-24X2.25-IN)
锁紧螺栓 |
2 | 187 |
| 6N-6490 |
BRACKET AS-FAN
|
1 | 187 |
| 1P-9946 |
SHAFT-FAN
|
1 | 187 |
| 4N-0684 |
DOWEL
销 |
1 | 187 |
| 7N-2900 |
RETAINER
固定器 |
1 | 187 |
| 7N-8827 |
HUB
|
1 | 187 |
| 8N-5305 |
SPACER (35.6X47.62X43.74-MM THK)
间隔套 |
1 | 187 |
| 9N-5120 |
BRACKET
支架 |
1 | 187 |
| 120-4879 |
ADAPTER
接头 |
1 | 187 |
| 0L-2070 |
BOLT (3/8-16X2.25-IN)
螺栓 |
6 | 187 |
| 1A-2029 |
BOLT (3/8-16X1.125-IN)
螺栓 |
2 | 187 |
| 1F-7958 |
NUT-FULL (1/2-13-THD)
全高螺母 |
2 | 187 |
| 1F-7960 |
WASHER (13.5X32X6-MM THK)
止推垫圈 |
4 | 187 |
| 2P-9084 |
STUD-TAPERLOCK
锥锁螺柱 |
2 | 187 |
| 3L-1425 |
BALL BEARING
球轴承 |
1 | 187 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
硬垫圈 |
2 | 187 |
| 5S-2106 |
SEAL-LIP TYPE
唇形油封 |
1 | 187 |
| 5S-9062 |
SPACER (35.032X50.8X15.88-MM THK)
间隔套 |
1 | 187 |
| 6N-0597 |
PULLEY-FAN DRIVE
|
1 | 187 |
| 8H-9789 |
BEARING AS-BALL
|
1 | 187 |
| 9F-4446 |
SEAL-O-RING
O 形密封圈 |
1 | 187 |
| 9L-4238 |
BOLT (3/8-16X8.5-IN)
螺栓 |
1 | 187 |
| 9X-8875 |
BOLT (1/2-13X3.5-IN)
螺栓 |
2 | 187 |
