| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 4L-5757 |
STRAP
接地束带 |
2 | 359 |
| 4V-1878 |
HOSE
泄放软管 |
2 | 359 |
| 5P-4868 |
CLAMP-HOSE
软管卡箍 |
4 | 359 |
| 5P-1262 |
HOSE (10-CM)
软管 |
1 | 359 |
| 7N-4600 |
BRACE AS
|
2 | 359 |
| 8D-3786 |
MOUNTING
安装件 |
2 | 359 |
| 005-4273 |
CONNECTOR-HOSE
软管接头 |
1 | 359 |
| 186-0712 |
PLATE
凸轮斜盘 |
4 | 359 |
| 228-2674 |
RADIATOR GP
|
1 | 359 |
| 228-4370 |
BRACE
支撑 |
1 | 359 |
| 228-4371 |
BRACE
支撑 |
1 | 359 |
| 228-4374 |
BRACKET
支架 |
1 | 359 |
| 228-4375 |
BRACKET
支架 |
1 | 359 |
| 228-4376 |
SUPPORT
支承 |
1 | 359 |
| 228-4377 |
SUPPORT
支承 |
1 | 359 |
| 228-4378 |
TUBE
管子 |
1 | 359 |
| 228-4379 |
TUBE
管子 |
1 | 359 |
| 228-9900 |
GUARD AS-FAN
|
2 | 359 |
| 164-1404 |
SPACER (10.67X16.95X23-MM THK)
间隔套 |
1 | 359 |
| 2S-7010 |
CLIP
卡箍 |
2 | 359 |
| 3D-2824 |
SEAL-O-RING (ID=23.47mm)
O 形密封圈 |
1 | 359 |
| 4L-9337 |
BOLT (3/8-16X1.5-IN)
螺栓 |
4 | 359 |
| 5M-3062 |
BOLT (3/8-16X0.75-IN)
螺栓 |
26 | 359 |
| 5P-0598 |
CLAMP-HOSE
软管卡箍 |
4 | 359 |
| 5P-1075 |
WASHER-HARD (10.2X22.5X3-MM THK)
硬垫圈 |
12 | 359 |
| 5P-9299 |
CLIP
卡箍 |
1 | 359 |
| 5S-7379 |
BOLT (3/8-16X0.875-IN)
螺栓 |
4 | 359 |
| 6B-5072 |
BUSHING-REDUCING
变径衬套 |
1 | 359 |
| 6V-8801 |
NUT (3/8-16-THD)
调速螺母 |
10 | 359 |
| 7T-8332 |
MOUNTING
安装件 |
4 | 359 |
| 7X-0301 |
BOLT (3/8-16X7-IN)
螺栓 |
2 | 359 |
| 7X-0312 |
BOLT (7/16-14X2.5-IN)
螺栓 |
4 | 359 |
| 7X-0313 |
BOLT (7/16-14X2.75-IN)
螺栓 |
2 | 359 |
| 7X-0384 |
BOLT (7/8-9X3-IN)
螺栓 |
8 | 359 |
| 7X-0447 |
NUT (7/16-14-THD)
调速螺母 |
6 | 359 |
| 7X-0618 |
WASHER-HARD (13.5X40X5-MM THK)
硬垫圈 |
8 | 359 |
| 8C-6913 |
WASHER-HARD (24X41.5X4-MM THK)
硬垫圈 |
8 | 359 |
| 8T-2502 |
BOLT (3/8-16X1.125-IN)
螺栓 |
2 | 359 |
| 8T-5360 |
WASHER (12X22.5X2.5-MM THK)
止推垫圈 |
6 | 359 |
| 8T-8917 |
BOLT (1/2-13X1.25-IN)
螺栓 |
8 | 359 |
| 9B-7237 |
BOLT (3/8-16X1.25-IN)
螺栓 |
6 | 359 |
