| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 243-0145 |
STATOR AS
|
1 | 525 |
| 243-0141 |
ROTOR AS
|
1 | 525 |
| 242-3919 |
FAN-GENERATOR
|
1 | 525 |
| 393-7035 |
FLANGE
|
1 | 525 |
| 6V-5684 |
BOLT (M12X1.75X45-MM)
|
6 | 525 |
| 242-3924 |
SCREEN
|
1 | 525 |
| 246-2207 |
BOLT (M6X1X40-MM)
|
2 | 525 |
| 242-3928 |
SHIELD
|
1 | 525 |
| 8T-4648 |
BOLT (M12X1.75X70-MM)
|
5 | 525 |
| 393-7036 |
GUARD GP-ALTERNATOR
|
1 | 525 |
| 243-5220 |
BEARING
|
1 | 525 |
| 241-4594 |
COVER
|
1 | 525 |
| 8T-6870 |
BOLT (M8X1.25X70-MM)
|
2 | 525 |
| 241-4595 |
CAP-BEARING
|
1 | 525 |
| 241-4597 |
RING
|
1 | 525 |
| 242-3938 |
EXCITER
|
1 | 525 |
| 102-7364 |
BOLT-SOCKET HEAD (M6X1X80-MM)
|
4 | 525 |
| 242-3941 |
ARMATURE
|
1 | 525 |
| 241-4606 |
SUPPORT-DIODE
|
1 | 525 |
| 242-3959 |
DISC-COUPLING
|
3 | 525 |
| 242-3960 |
SCREW (27.7-MMX40-MM)
|
8 | 525 |
| 241-4618 |
SHIM (2-MM THK)
|
1 | 525 |
| 241-4619 |
DIODE AS
|
1 | 525 |
| 241-4620 |
VARISTOR
|
1 | 525 |
| 241-4622 |
SEAL-O-RING
|
1 | 525 |
| 393-7040 |
BOX GP-GENERATOR CONNECTION
|
1 | 525 |
