| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 243-0148 |
STATOR AS
|
1 | 380 |
| 243-0144 |
ROTOR AS
|
1 | 380 |
| 242-3919 |
FAN-GENERATOR
|
1 | 380 |
| 241-4577 |
EYE-LIFTING
|
1 | 380 |
| 251-3488 |
FLANGE
|
1 | 380 |
| 160-8746 |
BOLT (M12X1.75X18-MM)
|
6 | 380 |
| 242-3924 |
SCREEN (AIR EXIT)
|
1 | 380 |
| 242-3926 |
SCREW (M11.5X50-MM)
|
2 | 380 |
| 242-3928 |
SHIELD
|
1 | 380 |
| 242-3929 |
SCREW (M22X70-THD)
|
5 | 380 |
| 242-3930 |
PANEL-TERMINAL BOX
|
1 | 380 |
| 242-3931 |
BOLT (M6X1X16-MM)
|
1 | 380 |
| 242-3932 |
SCREEN-AIR INLET
|
1 | 380 |
| 243-5380 |
CAP
|
1 | 380 |
| 243-5220 |
BEARING
|
1 | 380 |
| 241-4594 |
COVER
|
1 | 380 |
| 242-3936 |
SCREW (M15X70-MM)
|
2 | 380 |
| 241-4595 |
CAP-BEARING
|
1 | 380 |
| 241-4597 |
RING
|
1 | 380 |
| 242-3938 |
EXCITER
|
1 | 380 |
| 241-4633 |
BOLT (M6X1X80-MM)
|
4 | 380 |
| 242-3941 |
ARMATURE
|
1 | 380 |
| 241-4606 |
SUPPORT-DIODE
|
1 | 380 |
| 242-3943 |
TERMINAL AS
|
1 | 380 |
| 242-3951 |
TERMINAL
|
3 | 380 |
| 242-3956 |
TERMINAL
|
1 | 380 |
| 242-3957 |
SCREW (M12X50-MM)
|
9 | 380 |
| 289-4769 |
REGULATOR AS-VOLTAGE (GENERATOR)
|
1 | 380 |
| 251-3489 |
DISC-COUPLING
|
1 | 380 |
| 242-3960 |
SCREW (27.7-MMX40-MM)
|
8 | 380 |
| 241-4618 |
SHIM (2-MM THK)
|
1 | 380 |
| 241-4619 |
DIODE AS
|
1 | 380 |
| 241-4620 |
VARISTOR
|
1 | 380 |
| 241-4622 |
SEAL-O-RING
|
1 | 380 |
| 242-3965 |
PANEL (TERMINAL)
|
1 | 380 |
| 242-3966 |
PANEL
|
1 | 380 |
| 242-3967 |
PANEL
|
1 | 380 |
| 242-3968 |
PANEL-ACCESS
|
1 | 380 |
| 307-6560 |
BRACKET
|
1 | 380 |
| 6V-8801 |
NUT (3/8-16-THD)
|
1 | 380 |
| 8T-0400 |
STEM AS-COLLET
|
1 | 380 |
| 8T-0192 |
BOLT (3/8-16X2.25-IN)
|
1 | 380 |
| 4D-1326 |
LOCKWASHER
|
1 | 380 |
| 8T-4896 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
1 | 380 |
