| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 160-8734 |
160-8734
|
1 | 490 |
| 165-9577 |
165-9577
|
1 | 490 |
| 1P-4578 |
FLANGE
|
2 | 491 |
| 8T-4223 |
WASHER
|
18 | 491 |
| 1P-4579 |
FLANGE
|
2 | 491 |
| 187-6051 |
BLOCK
|
1 | 491 |
| 4J-0524 |
SEAL - O - RING (ID=47.22mm)
|
2 | 491 |
| 1P-3705 |
SEAL
|
7 | 491 |
| 149-6556 |
BLOCK
|
1 | 491 |
| 9S-4183 |
PLUG
|
1 | 491 |
| 187-6053 |
TUBE AS
|
1 | 491 |
| 149-6557 |
TUBE AS
|
1 | 491 |
| 1P-3706 |
SEAL
|
2 | 491 |
| 124-0909 |
CLIP
|
2 | 491 |
| 165-9576 |
VALVE AS
|
1 | 491 |
| 1P-5767 |
FLANGE
|
4 | 491 |
| 8T-4184 |
BOLT (L=45mm)
|
8 | 491 |
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
1 | 491 |
| 9X-8257 |
WASHER
|
2 | 491 |
| 9S-6130 |
PLUG
|
1 | 491 |
| 1P-3704 |
SEAL
|
2 | 491 |
| 168-9293 |
HOSE AS
|
1 | 491 |
| 8T-4648 |
BOLT (L=70mm)
|
2 | 491 |
| 168-9292 |
BLOCK
|
1 | 491 |
| 149-6566 |
SUPPORT AS
|
1 | 491 |
| 187-6700 |
TUBE AS
|
1 | 491 |
| 8T-4956 |
BOLT (L=35mm)
|
20 | 491 |
| 187-5899 |
SUPPORT AS
|
1 | 491 |
| 7X-2556 |
BOLT (L=100mm)
|
4 | 491 |
| 165-9577 |
VALVE AS
|
1 | 491 |
| 8T-7338 |
BOLT (L=45mm)
|
4 | 491 |
| 2S-4078 |
SEAL - O - RING (ID=37.47mm)
|
1 | 491 |
| 212-5336 |
HOSE AS
|
1 | 491 |
| 152-9198 |
SUPPORT AS
|
1 | 491 |
| 8T-4176 |
BOLT (L=90mm)
|
8 | 491 |
| 160-8734 |
VALVE GP
|
2 | 491 |
| 152-9171 |
TUBE AS
|
1 | 491 |
| 8T-4195 |
BOLT (L=30mm)
|
8 | 491 |
| 8T-4140 |
BOLT (L=60mm)
|
2 | 491 |
| 8T-5092 |
BOLT (L=150mm)
|
8 | 491 |
| 152-9243 |
SUPPORT
|
1 | 491 |
| 8T-4183 |
BOLT (L=40mm)
|
2 | 491 |
| 8T-4192 |
BOLT (L=25mm)
|
2 | 491 |
| 165-9579 |
VALVE GP
|
1 | 491 |
| 8T-4121 |
WASHER
|
4 | 491 |
| 168-9296 |
PIPE AS
|
1 | 491 |
| 4J-0522 |
SEAL - O - RING (ID=37.69mm)
|
2 | 491 |
