| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 6V-3916 |
BALL BEARING
球轴承 |
1 | 525 |
| 1L-8497 |
RING-SNAP (SMALL)
|
1 | 525 |
| 6J-7855 |
RING-RETAINING (LARGE)
挡圈 |
1 | 525 |
| 5N-8383 |
CYLINDER
油缸 |
1 | 525 |
| 5N-8375 |
CUP-SPRING
|
1 | 525 |
| 6V-3935 |
RING-RETAINING
挡圈 |
1 | 525 |
| 5N-8381 |
SPRING-CLUTCH
|
1 | 525 |
| 5N-9574 |
JAW AS-CLUTCH
|
1 | 525 |
| 5N-8387 |
CASE-GEAR
|
1 | 525 |
| 5N-8424 |
BULKHEAD
|
1 | 525 |
| 3B-4505 |
LOCKWASHER
锁紧垫圈 |
8 | 525 |
| 3J-7719 |
RING-RETAINING (INNER)
挡圈 |
1 | 525 |
| 6V-3971 |
RING-RETAINING (OUTER)
挡圈 |
1 | 525 |
| 7F-8671 |
BALL BEARING
球轴承 |
1 | 525 |
| 5N-8428 |
WASHER-GEAR (10.1X34X15.5-MM THK)
|
1 | 525 |
| 6V-3959 |
LOCKWASHER
锁紧垫圈 |
5 | 525 |
| 5N-8425 |
WASHER (12.2X41.5X4.5-MM THK)
垫圈 |
1 | 525 |
| 7W-1650 |
PINION-DRIVE (11-TEETH)
|
1 | 525 |
| 5N-8374 |
SLEEVE-SPRING
|
1 | 525 |
| 5N-8380 |
SPRING-PINION
|
1 | 525 |
| 2W-6082 |
KIT-DRIVE (AIR STARTING MOTOR)
|
1 | 525 |
| 8B-7624 |
BALL BEARING
球轴承 |
1 | 525 |
| 5N-8379 |
SEAT-SPRING
|
1 | 525 |
| 5N-8372 |
SPRING-RETURN
|
1 | 525 |
| 5N-8384 |
SHAFT-DRIVE
主动轴 |
1 | 525 |
| 5N-8363 |
COVER AS
前盖组件 |
1 | 525 |
| 4D-3118 |
PLUG-PIPE
管螺塞 |
3 | 525 |
| 5N-8377 |
BEARING-DRIVE SHAFT
|
1 | 525 |
| 5N-8373 |
PISTON
制动活塞 |
1 | 525 |
| 5N-8368 |
PINION-ROTOR (17-TEETH)
|
1 | 525 |
| 5N-8365 |
PLATE-FRONT END
|
1 | 525 |
| 6V-1394 |
BALL BEARING
球轴承 |
1 | 525 |
| 039-4317 |
WASHER-SPRING
弹簧垫圈 |
2 | 525 |
| 5N-8364 |
HOUSING-MOTOR
|
1 | 525 |
| 7W-4154 |
ROTOR
转子 |
1 | 525 |
| 5N-8367 |
PLATE-REAR END
|
1 | 525 |
| 5P-9514 |
BALL BEARING
球轴承 |
1 | 525 |
| 5N-8378 |
NUT-ROTOR CLAMP (M5X0.8-THD)
|
1 | 525 |
