| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 8N-7296 |
RETAINER-PIN
|
2 | 107 |
| 121-3558 |
RETAINER AS
|
1 | 107 |
| 6V-3537 |
DOWEL
|
1 | 107 |
| 138-8508 |
PIN-PISTON
|
1 | 107 |
| 144-5695 |
RING-PISTON (INTERMEDIATE)
|
1 | 107 |
| 165-6668 |
RING-PISTON (OIL CONTROL)
|
1 | 107 |
| 207-1372 |
TUBE AS
|
1 | 107 |
| 229-1632 |
RING-PISTON (TOP)
|
1 | 107 |
| 230-2516 |
ROD AS
|
1 | 107 |
| 7N-2043 |
DOWEL
|
1 | 107 |
| 7N-2405 |
BOLT-CONNECTING ROD
|
4 | 107 |
| 230-2519 |
BEARING-SLEEVE
|
1 | 107 |
| 230-2520 |
BEARING-CONNECTING ROD
|
1 | 107 |
| 293-5429 |
PISTON GP
|
1 | 107 |
| 155-5271 |
SKIRT-PISTON
|
1 | 107 |
| 0T-0102 |
BOLT (3/8-16X0.625-IN)
|
1 | 107 |
| 1B-2790 |
BOLT (5/16-18X1.375-IN)
|
1 | 107 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
1 | 107 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
|
1 | 107 |
| 8N-7296 |
RETAINER-PIN
|
2 | 108 |
| 121-3558 |
RETAINER AS
|
1 | 108 |
| 6V-3537 |
DOWEL
|
1 | 108 |
| 138-8508 |
PIN-PISTON
|
1 | 108 |
| 144-5695 |
RING-PISTON (INTERMEDIATE)
|
1 | 108 |
| 165-6668 |
RING-PISTON (OIL CONTROL)
|
1 | 108 |
| 207-1372 |
TUBE AS
|
1 | 108 |
| 229-1632 |
RING-PISTON (TOP)
|
1 | 108 |
| 230-2516 |
ROD AS
|
1 | 108 |
| 7N-2043 |
DOWEL
|
1 | 108 |
| 7N-2405 |
BOLT-CONNECTING ROD
|
4 | 108 |
| 230-2519 |
BEARING-SLEEVE
|
1 | 108 |
| 230-2520 |
BEARING-CONNECTING ROD
|
1 | 108 |
| 283-0245 |
PISTON AS
|
1 | 108 |
| 155-5271 |
SKIRT-PISTON
|
1 | 108 |
| 0T-0102 |
BOLT (3/8-16X0.625-IN)
|
1 | 108 |
| 1B-2790 |
BOLT (5/16-18X1.375-IN)
|
1 | 108 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
1 | 108 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
|
1 | 108 |
| 4W-0335 |
KIT-BUSHING (CRANKSHAFT PULLEY) (INCLUDES BUSHING, BOLTS, LOCKWASHER, SET SCREW AND KEY)
|
1 | 109 |
| 4W-0335 |
KIT-BUSHING (CRANKSHAFT PULLEY) (INCLUDES BUSHING, BOLTS, LOCKWASHER, SET SCREW AND KEY)
|
1 | 110 |
