| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 1D-4540 |
BOLT (5/16-18X2.75-IN)
|
6 | 382 |
| 7E-4475 |
TUBE-SPACER (8.3X11.9X50.8-MM THK)
|
6 | 382 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
|
6 | 382 |
| 128-0594 |
COVER-DRIP
|
1 | 382 |
| 9X-8882 |
BOLT (5/8-11X2.5-IN)
|
8 | 391 |
| 127-4374 |
SEAL
|
1 | 391 |
| 154-3414 |
ADAPTER AS-HOUSING
|
1 | 391 |
| 7M-5130 |
PIN-SPRING
|
1 | 391 |
| 152-5183 |
SLEEVE-WEAR
|
1 | 391 |
| 0S-1588 |
BOLT (3/8-16X1.25-IN)
|
4 | 391 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
4 | 391 |
| 5P-8247 |
WASHER-HARD (17X32X3.5-MM THK)
|
8 | 391 |
| 127-4374 |
SEAL
|
1 | 394 |
| 130-3654 |
BAR-SUPPORT
|
1 | 394 |
| 152-5181 |
BRACKET AS-HOUSING
|
1 | 394 |
| 7M-5130 |
PIN-SPRING
|
1 | 394 |
| 152-5183 |
SLEEVE-WEAR
|
1 | 394 |
| 152-5338 |
RETAINER-BAR
|
2 | 394 |
| 0S-1571 |
BOLT (3/8-16X1.75-IN)
|
4 | 394 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
4 | 394 |
| 5P-8245 |
WASHER-HARD (13.5X25.5X3-MM THK)
|
2 | 394 |
| 5P-8247 |
WASHER-HARD (17X32X3.5-MM THK)
|
8 | 394 |
| 9S-1366 |
BOLT (1/2-13X2.5-IN)
|
2 | 394 |
| 9X-8882 |
BOLT (5/8-11X2.5-IN)
|
8 | 394 |
| 4P-4506 |
INSULATOR
|
1 | 401 |
| 9Y-4275 |
FILM (TERMINAL STRIP)
|
1 | 401 |
| 126-7607 |
BRACKET-MOUNTING
|
7 | 401 |
| 126-7609 |
BRACKET-MOUNTING
|
1 | 401 |
| 126-7610 |
BRACKET-MOUNTING
|
1 | 401 |
| 126-7612 |
BRACKET-SUPPORT
|
1 | 401 |
| 154-1903 |
STRIP-TERMINAL
|
3 | 401 |
| 154-1904 |
STRIP-TERMINAL
|
1 | 401 |
| 0S-1591 |
BOLT (3/8-16X1.5-IN)
|
6 | 401 |
| 0S-1594 |
BOLT (3/8-16X1-IN)
|
2 | 401 |
| 0S-1618 |
BOLT (5/16-18X1-IN)
|
36 | 401 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
14 | 401 |
| 5S-0003 |
NUT (5/16-18 THD)
|
34 | 401 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
|
70 | 401 |
| 9S-8752 |
NUT-FULL (3/8-16-THD)
|
6 | 401 |
| 108-5749 |
ROTOR AS-MAGNETIC
|
1 | 403 |
| 117-0017 |
RING
|
1 | 403 |
| 125-3425 |
STATOR AS-MAGNET
|
1 | 403 |
| 0S-1591 |
BOLT (3/8-16X1.5-IN)
|
4 | 403 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
4 | 403 |
| 5P-0537 |
WASHER-HARD (7.2X14.5X2-MM THK)
|
4 | 403 |
| 9F-7022 |
BOLT (1/4-20X1.5-IN)
|
4 | 403 |
| 206-6224 |
ROTOR-EXCITER
|
1 | 404 |
| 215-2404 |
STATOR-EXCITER
|
1 | 404 |
| 8H-8769 |
BOLT (5/16-18X4.25-IN)
|
4 | 404 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
|
4 | 404 |
