| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 2W-8811 |
SUPPORT
|
1 | 1019 |
| 8N-9300 |
MOUNT AS
|
2 | 1019 |
| 2N-3474 |
SCREW (6-32X.375IN)
|
4 | 1019 |
| 5H-6555 |
LOCKWASHER-TOOTH (NO.4)
|
4 | 1019 |
| 4B-2041 |
NUT (6-32 THD)
|
4 | 1019 |
| 2W-1769 |
PLATE
|
1 | 1019 |
| 1W-5280 |
INDICATOR-PRESSURE
|
1 | 1019 |
| 6K-1972 |
ELBOW-FLARED (1/4 NPT)
|
2 | 1019 |
| 7S-4338 |
SCREW-MACHINE (8-32X.75IN)
|
2 | 1019 |
| 1H-4393 |
LOCKWASHER (NO.8)
|
2 | 1019 |
| 8S-4711 |
BOLT (1/4-20X4.5IN)
|
2 | 1019 |
| 5P-0537 |
WASHER (2MM THK)
|
2 | 1019 |
| 3T-3848 |
HOSE AS
|
1 | 1019 |
| 3N-5992 |
AMMETER
|
1 | 1020 |
| 3N-5990 |
FILM-GAUGE IDENTIFICATION
|
1 | 1020 |
| 2N-1287 |
ELBOW-FLARED
|
2 | 1021 |
| 8N-8432 |
TUBE AS
|
1 | 1021 |
| 4D-8948 |
CLIP (1/4IN X17/32IN SLOT)
|
1 | 1021 |
| 7W-6147 |
PLATE
|
1 | 1021 |
| 2V-5956 |
HOSE AS
|
2 | 1021 |
| 7B-2742 |
BOLT (1/4-20X1.25IN)
|
1 | 1021 |
| 9S-8750 |
NUT-FULL (1/4-20 THD)
|
2 | 1021 |
| 5P-0537 |
WASHER (2MM THK)
|
4 | 1021 |
| 6H-1717 |
BOLT (1/2-13X1.125IN)
|
1 | 1021 |
| 5P-8245 |
WASHER (3MM THK)
|
1 | 1021 |
| 8B-9725 |
BOSS
|
1 | 1021 |
| 9F-6580 |
BOLT (1/4-20X1.125IN)
|
1 | 1021 |
| 5P-9287 |
WASHER-HARD
|
2 | 1021 |
| 0S-1594 |
BOLT (3/8-16X1IN)
|
1 | 1021 |
| 5M-2894 |
WASHER (2.5MM THK)
|
1 | 1021 |
| 067-6495 |
ELBOW-FLARED
|
2 | 1021 |
| 8N-8470 |
BRACKET
|
1 | 1021 |
| 8N-8472 |
CLAMP-TUBE
|
1 | 1021 |
| 7B-2742 |
BOLT (1/4-20X1.25IN)
|
2 | 1021 |
| 3J-7355 |
UNION-FLARED
|
2 | 1021 |
| 5N-9230 |
CLAMP-TUBE
|
2 | 1021 |
| 124-0174 |
CLIP (12.7MM ID)
|
2 | 1021 |
| 8N-5698 |
TUBE AS
|
1 | 1021 |
| 1W-8121 |
TUBE AS
|
1 | 1021 |
| 1W-8120 |
TUBE AS
|
1 | 1021 |
| 6V-7646 |
WASHER-HARD (2MM THK)
|
1 | 1021 |
| 5P-0537 |
WASHER (2MM THK)
|
1 | 1021 |
| 7C-0813 |
TUBE AS
|
1 | 1023 |
| 4W-4563 |
TUBE AS
|
1 | 1023 |
| 7B-2742 |
BOLT (1/4-20X1.25IN)
|
4 | 1023 |
| 9S-8750 |
NUT-FULL (1/4-20 THD)
|
4 | 1023 |
| 5P-0537 |
WASHER (2MM THK)
|
9 | 1023 |
| 0S-1594 |
BOLT (3/8-16X1IN)
|
2 | 1023 |
| 5M-2894 |
WASHER (2.5MM THK)
|
2 | 1023 |
| 8N-8470 |
BRACKET
|
2 | 1023 |
