| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 6K-1972 |
ELBOW-FLARED
|
2 | 1049 |
| 5N-8980 |
VALVE AS-SOLENOID (AIR START)
|
1 | 1049 |
| 454-7489 |
SWITCH AS-PUSH BUTTON (ENGINE START)
|
1 | 1049 |
| 0S-1591 |
BOLT (3/8-16X1.5-IN)
|
2 | 1049 |
| 9S-8752 |
NUT-FULL (3/8-16-THD)
|
2 | 1049 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
2 | 1049 |
| 5P-1075 |
WASHER-HARD (10.2X22.5X3-MM THK)
|
2 | 1049 |
| 7D-5473 |
BOLT-SOCKET HEAD (8-32X0.75-IN)
|
4 | 1049 |
| 4B-2043 |
NUT (8-32-THD)
|
4 | 1049 |
| 3B-4501 |
LOCKWASHER
|
1 | 1049 |
| 5H-7598 |
NIPPLE-PIPE
|
1 | 1049 |
| 2V-5956 |
HOSE AS
|
1 | 1049 |
| 5N-8980 |
VALVE AS-SOLENOID (AIR START)
|
1 | 1051 |
| 6K-1972 |
ELBOW-FLARED
|
2 | 1051 |
| 5H-7598 |
NIPPLE-PIPE
|
1 | 1051 |
| 2V-5956 |
HOSE AS
|
1 | 1051 |
| 4M-5317 |
BUSHING-REDUCER
|
1 | 1051 |
| 5F-5434 |
VALVE AS-VENT
|
1 | 1051 |
| 030-7961 |
ELBOW
|
1 | 1051 |
| 6I-1966 |
PLATE-CONTROL MOUNTING
|
1 | 1052 |
| 2V-5956 |
HOSE AS
|
1 | 1052 |
| 3F-2065 |
LOCKNUT (1/2-14-THD)
|
1 | 1052 |
| 4F-8184 |
BUSHING-TERMINAL
|
1 | 1052 |
| 5N-2746 |
VALVE-SOLENOID
|
1 | 1052 |
| 5P-5610 |
CONNECTOR
|
2 | 1052 |
| 6I-1997 |
SWITCH (AIR STARTING)
|
1 | 1052 |
| 6N-9587 |
CONNECTOR
|
2 | 1052 |
| 165-3929 |
BOLT (3/8-16X1.5-IN)
|
2 | 1052 |
| 3B-4501 |
LOCKWASHER
|
4 | 1052 |
| 4B-2043 |
NUT (8-32-THD)
|
4 | 1052 |
| 5H-7598 |
NIPPLE-PIPE
|
1 | 1052 |
| 5L-2579 |
GROMMET
|
1 | 1052 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
2 | 1052 |
| 5P-1075 |
WASHER-HARD (10.2X22.5X3-MM THK)
|
2 | 1052 |
| 6K-1972 |
ELBOW-FLARED
|
2 | 1052 |
| 7D-5473 |
BOLT-SOCKET HEAD (8-32X0.75-IN)
|
4 | 1052 |
| 7J-8611 |
ELBOW-PIPE
|
1 | 1052 |
| 9S-8752 |
NUT-FULL (3/8-16-THD)
|
2 | 1052 |
| 5N-8980 |
VALVE AS-SOLENOID (AIR START)
|
1 | 1054 |
| 6I-1966 |
PLATE-CONTROL MOUNTING
|
1 | 1054 |
| 7D-5473 |
BOLT-SOCKET HEAD (8-32X0.75-IN)
|
4 | 1054 |
| 4B-2043 |
NUT (8-32-THD)
|
4 | 1054 |
| 3B-4501 |
LOCKWASHER
|
4 | 1054 |
| 6K-1972 |
ELBOW-FLARED
|
1 | 1054 |
| 5H-7598 |
NIPPLE-PIPE
|
1 | 1054 |
| 6N-3170 |
HOSE AS
|
1 | 1054 |
| 6I-1998 |
SWITCH AS-PUSH BUTTON (ENGINE START)
|
1 | 1054 |
| 0S-1591 |
BOLT (3/8-16X1.5-IN)
|
2 | 1054 |
| 9S-8752 |
NUT-FULL (3/8-16-THD)
|
2 | 1054 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
2 | 1054 |
