| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 3L-6008 |
SPACER (10.5X19X28.6-MM THK)
|
1 | 467 |
| 7D-8793 |
ELBOW-FLARED
|
1 | 467 |
| 7W-4979 |
VALVE-CHECK
|
1 | 467 |
| 113-9001 |
HOSE AS
|
1 | 467 |
| 169-7326 |
VALVE-BALL (SHUTOFF, OIL)
|
1 | 467 |
| 216-8359 |
HOSE AS
|
1 | 467 |
| 1F-0750 |
NUT-WELD (3/8-16-THD)
|
2 | 467 |
| 032-1267 |
CONNECTOR (STRAIGHT)
|
1 | 467 |
| 0L-1143 |
BOLT (3/8-16X2.5-IN)
|
2 | 467 |
| 0L-2070 |
BOLT (3/8-16X2.25-IN)
|
1 | 467 |
| 0S-1594 |
BOLT (3/8-16X1-IN)
|
2 | 467 |
| 2N-8037 |
ELBOW
|
1 | 467 |
| 3B-7255 |
BUSHING-REDUCER
|
1 | 467 |
| 3B-7741 |
NIPPLE-PIPE (CLOSE)
|
2 | 467 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
5 | 467 |
| 8L-3282 |
CONNECTOR
|
1 | 467 |
| 8M-2773 |
CLIP (LOOP)
|
1 | 467 |
