| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 2H-3880 |
SCREW-DRIVE (#2X1/8)
|
2 | 707 |
| 5N-1782 |
PLATE-IDENTIFICATION (HYDROMECHANICAL SHUTOFF)
|
1 | 707 |
| 5N-6711 |
COVER
先导盖 |
1 | 707 |
| 5N-2707 |
GASKET
密封垫 |
1 | 707 |
| 5M-6213 |
PLUG-PIPE
管螺塞 |
5 | 707 |
| 5N-2709 |
BOLT (1/4-28X2.5-IN)
螺栓 |
1 | 707 |
| 4F-7957 |
BOLT (1/4-20X0.875-IN)
螺栓 |
3 | 707 |
| 5N-6443 |
VALVE GP-FUEL SHUTOFF
|
1 | 707 |
| 2A-4781 |
BOLT (1/4-20X2.75-IN)
螺栓 |
5 | 707 |
| 8S-4710 |
BOLT (1/4-20X4-IN)
螺栓 |
3 | 707 |
| 5N-4718 |
GASKET
密封垫 |
1 | 707 |
| 5N-4727 |
COVER
先导盖 |
1 | 707 |
| 5N-2725 |
GASKET
密封垫 |
1 | 707 |
| 5N-2716 |
BOLT (1/4-28X1.1-IN)
螺栓 |
1 | 707 |
| 172-0264 |
SEAT
座圈 |
1 | 707 |
| 5N-4728 |
SEAT
座圈 |
1 | 707 |
| 6N-3504 |
SEAT-GOVERNOR SPRING
|
1 | 707 |
| 8M-1682 |
SPRING
制动弹簧 |
1 | 707 |
| 5N-2718 |
VALVE GP-SPEED SENSING
|
1 | 707 |
| 6H-3958 |
BOLT-SOCKET HEAD (1/4-20X2.5-IN)
内六角螺栓 |
1 | 707 |
| 6J-2819 |
BOLT-SOCKET HEAD (1/4-20X2.75-IN)
内六角螺栓 |
7 | 707 |
| 5N-5990 |
VALVE GP-PRESSURE CONTROL
|
1 | 707 |
| 5N-6141 |
HOUSING AS-CONTROL
|
1 | 707 |
| 5N-3198 |
GASKET
密封垫 |
1 | 707 |
| 032-1267 |
CONNECTOR-FLARED
|
2 | 707 |
| 5N-4990 |
TUBE AS
右管子组件 |
1 | 707 |
| 3R-6569 |
BOLT (1/4-20X0.875-IN)
螺栓 |
1 | 707 |
| 032-1268 |
CONNECTOR (90-DEG)
接头 |
5 | 707 |
| 6K-9194 |
ELBOW
弯头 |
1 | 707 |
| 2H-3880 |
SCREW-DRIVE (#2X1/8)
|
2 | 967 |
| 5N-1782 |
PLATE-IDENTIFICATION (HYDROMECHANICAL SHUTOFF)
|
1 | 967 |
| 5N-6711 |
COVER
先导盖 |
1 | 967 |
| 5N-2707 |
GASKET
密封垫 |
1 | 967 |
| 5M-6213 |
PLUG-PIPE
管螺塞 |
5 | 967 |
| 5N-2709 |
BOLT (1/4-28X2.5-IN)
螺栓 |
1 | 967 |
| 4F-7957 |
BOLT (1/4-20X0.875-IN)
螺栓 |
3 | 967 |
| 5N-6443 |
VALVE GP-FUEL SHUTOFF
|
1 | 967 |
| 2A-4781 |
BOLT (1/4-20X2.75-IN)
螺栓 |
5 | 967 |
| 8S-4710 |
BOLT (1/4-20X4-IN)
螺栓 |
3 | 967 |
| 5N-4718 |
GASKET
密封垫 |
1 | 967 |
| 5N-4727 |
COVER
先导盖 |
1 | 967 |
| 5N-2725 |
GASKET
密封垫 |
1 | 967 |
| 5N-2716 |
BOLT (1/4-28X1.1-IN)
螺栓 |
1 | 967 |
| 172-0264 |
SEAT
座圈 |
1 | 967 |
| 5N-4728 |
SEAT
座圈 |
1 | 967 |
| 6N-3504 |
SEAT-GOVERNOR SPRING
|
1 | 967 |
| 8M-1682 |
SPRING
制动弹簧 |
1 | 967 |
| 5N-2718 |
VALVE GP-SPEED SENSING
|
1 | 967 |
| 6H-3958 |
BOLT-SOCKET HEAD (1/4-20X2.5-IN)
|
1 | 967 |
| 6J-2819 |
BOLT-SOCKET HEAD (1/4-20X2.75-IN)
|
7 | 967 |
