| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 5N-8353 |
HOSE AS
|
1 | 553 |
| 5N-8352 |
HOSE AS
|
1 | 553 |
| 002-6453 |
ELBOW-PIPE
|
2 | 553 |
| 2H-9091 |
CONNECTOR-PIPE
|
1 | 553 |
| 3B-7272 |
NIPPLE-PIPE (1/2-14 NPT THD)
|
1 | 553 |
| 7W-0522 |
LUBRICATOR GP-AIR MOTOR
|
1 | 553 |
| 2W-9585 |
PIPE-LH
|
1 | 555 |
| 6V-5167 |
SEAL-O-RING (139.07MM ID)
|
4 | 555 |
| 6V-3319 |
SEAL-O-RING (158.34MM ID)
|
2 | 555 |
| 7E-8550 |
FLANGE
|
2 | 555 |
| 0S-1619 |
BOLT (3/8-16X3.0IN)
|
2 | 555 |
| 5M-2894 |
WASHER (2.5MM THK)
|
148 | 555 |
| 4W-0715 |
MANIFOLD-INLET
|
1 | 555 |
| 1W-1251 |
GASKET
|
5 | 555 |
| 1A-2029 |
BOLT (3/8-16X1.125IN)
|
40 | 555 |
| 6V-3917 |
SEAL-O-RING (94.62MM ID)
|
4 | 555 |
| 8T-6765 |
PLUG-PIPE (1/4-18 NPTF THD)
|
3 | 555 |
| 2W-1640 |
BRACKET
|
1 | 555 |
| 0L-1329 |
BOLT (1/2-13X3 IN)
|
2 | 555 |
| 5P-8245 |
WASHER-HARD (3MM THK)
|
2 | 555 |
| 7N-5079 |
ELBOW
|
12 | 555 |
| 7N-5085 |
FLANGE
|
12 | 555 |
| 7N-5080 |
GASKET-MANIFOLD
|
12 | 555 |
| 5P-0076 |
BOLT-12 POINT HEAD (3/8-16X1.50IN)
|
96 | 555 |
| 7N-5089 |
GASKET
|
12 | 555 |
| 6V-5504 |
SEAL-O-RING (107.32MM ID)
|
12 | 555 |
| 5L-3773 |
GASKET-EXHAUST ELBOW
|
1 | 555 |
| 9S-8752 |
NUT (3/8-16 THD)
|
8 | 555 |
| 3J-5389 |
PLUG (1/2-14 NPT THD)
|
2 | 555 |
| 2W-9584 |
PIPE-RH
|
1 | 555 |
| 140-0407 |
ELBOW-EXHAUST
|
1 | 555 |
| 4W-6964 |
BRACKET
|
2 | 555 |
| 3V-3308 |
WASHER (2.5MM THK)
|
2 | 555 |
| 8M-7145 |
WASHER (5MM THK)
|
2 | 555 |
| 0T-0573 |
BOLT (3/8-16X2.75IN)
|
4 | 555 |
| 1W-1250 |
COVER
|
1 | 555 |
| 0L-1351 |
BOLT (3/8-16X.875IN)
|
2 | 555 |
| 7W-1944 |
RETAINER
|
2 | 555 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
|
4 | 471 |
| 0S-1594 |
BOLT (3/8-16X1-IN)
|
2 | 471 |
| 7W-7457 |
BRACKET
|
1 | 471 |
| 7J-8611 |
ELBOW-PIPE
|
1 | 471 |
| 002-6453 |
ELBOW
|
1 | 471 |
| 032-1268 |
CONNECTOR (90-DEG)
|
1 | 471 |
| 0L-1143 |
BOLT (3/8-16X2.5-IN)
|
2 | 471 |
| 8T-0169 |
ELBOW
|
1 | 471 |
| 5L-5006 |
REGULATOR-LEVEL (ENGINE OIL)
|
1 | 471 |
| 6B-5072 |
ADAPTER
|
2 | 471 |
| 5N-7766 |
HOSE AS
|
1 | 471 |
| 3B-7722 |
BUSHING-PIPE
|
1 | 471 |
