| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 6V-8377 |
NUT (8-32 THD)
|
1 | 893 |
| 9B-7233 |
LOCKWASHER
|
2 | 893 |
| 2W-6382 |
SHAFT-SOLENOID
|
1 | 893 |
| 8L-3873 |
GASKET
|
1 | 893 |
| 0S-1615 |
BOLT (1/4-20X.75 IN)
|
2 | 893 |
| 1A-8912 |
WASHER (6.7X12.7X1.6MM THK)
|
2 | 893 |
| 1W-9070 |
DIODE AS
|
1 | 893 |
| 1H-4560 |
NIPPLE-PLUG
|
2 | 893 |
| 7W-6958 |
SHIELD
|
1 | 893 |
| 2W-6507 |
SHIELD
|
1 | 893 |
| 5P-0537 |
WASHER-HARD (7.2X14.5X2MM THK)
|
4 | 893 |
| 9S-8750 |
NUT-FULL (1/4-20 THD)
|
2 | 893 |
| 7B-2742 |
BOLT (1/4-20X1.25 IN)
|
2 | 893 |
| 129-3021 |
RING
|
1 | 893 |
| 2W-6382 |
SHAFT-SOLENOID
|
1 | 894 |
| 5L-8983 |
SPRING-SOLENOID
|
1 | 894 |
| 9W-0755 |
SOLENOID AS
|
1 | 894 |
| 6V-8377 |
NUT (8-32 THD)
|
4 | 894 |
| 4B-4863 |
WASHER (4.7X11X1.2MM THK)
|
2 | 894 |
| 6V-8244 |
PLATE-SOLENOID INFORMATION
|
1 | 894 |
| 1H-4560 |
NIPPLE-PLUG
|
2 | 894 |
| 1W-9070 |
DIODE AS
|
1 | 894 |
| 4P-5645 |
SHIELD AS
|
1 | 894 |
| 0S-1615 |
BOLT (1/4-20X0.75 IN)
|
4 | 894 |
| 9S-8750 |
NUT-FULL (1/4-20 THD)
|
2 | 894 |
| 5P-0537 |
WASHER-HARD (7.2X14.5X2MM THK)
|
4 | 894 |
| 1A-8912 |
WASHER (6.7X12.7X1.6MM THK)
|
2 | 894 |
| 8L-3873 |
GASKET
|
1 | 894 |
| 4P-5644 |
SHIELD
|
1 | 894 |
| 5N-8954 |
WASHER
|
1 | 895 |
| 8L-3873 |
GASKET
|
1 | 895 |
| 0S-1615 |
BOLT (1/4-20X0.75 IN)
|
2 | 895 |
| 1A-8912 |
WASHER (6.7X12.7X1.6MM THK)
|
2 | 895 |
| 7T-0491 |
SOLENOID-AIR
|
1 | 895 |
| 1H-4560 |
NIPPLE-PLUG
|
2 | 895 |
| 1W-9070 |
DIODE AS
|
1 | 895 |
| 6V-2689 |
TUBE-SHRINKABLE (6.35MM ID)
|
1 | 895 |
| 7N-9194 |
TERMINAL
|
2 | 895 |
| 5L-8983 |
SPRING-SOLENOID
|
1 | 895 |
| 5N-2336 |
SHIELD
|
1 | 895 |
| 9X-7137 |
VALVE AS-ETHER
|
1 | 897 |
| 7N-7779 |
SOCKET
|
1 | 897 |
| 7N-7780 |
PIN-CONNECTOR (BLADE)
|
1 | 897 |
| 7N-9737 |
HOUSING-PLUG
|
1 | 897 |
| 7X-7773 |
FILM-NOTICE (ETHER SYSTEM)
|
1 | 897 |
| 9X-7138 |
FILTER & GASKET AS
|
1 | 897 |
| 7N-2059 |
CLAMP AS-CYLINDER
|
1 | 897 |
| 160-8766 |
FITTING AS
|
1 | 897 |
| 160-8761 |
FILTER-FITTING
|
1 | 897 |
| 1N-3416 |
TUBE-STEEL
|
1 | 897 |
