| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 6I-0850 |
HOUSING-COMPRESSOR
|
1 | 581 |
| 118-2988 |
CARTRIDGE GP-TURBOCHARGER
|
1 | 581 |
| 1W-4795 |
PLATE-IDENTIFICATION
|
1 | 581 |
| 2F-0808 |
SCREW
|
2 | 581 |
| 119-3686 |
HOUSING-TURBINE
|
1 | 581 |
| 9N-2038 |
CLAMP AS
|
1 | 581 |
| 7M-9918 |
LOCKNUT
|
1 | 581 |
| 7W-2297 |
CLAMP AS
|
1 | 581 |
| 121-5736 |
GASKET-TURBOCHARGER
|
2 | 582 |
| 2N-2765 |
BOLT-HIGH TEMPERATURE (3/8-16X1.75IN)
|
8 | 582 |
| 168-7800 |
LOCKNUT (HIGH TEMPERATURE)
|
8 | 582 |
| 124-5514 |
COUPLING-EXHAUST
|
2 | 582 |
| 6L-3005 |
CLAMP-V-BAND (EACH INCLUDES)
|
2 | 582 |
| 8T-0122 |
NUT-FULL (HIGH TEMPERATURE)
|
1 | 582 |
| 6I-0850 |
HOUSING-COMPRESSOR
|
1 | 785 |
| 118-2988 |
CARTRIDGE GP-TURBOCHARGER
|
1 | 785 |
| 119-3686 |
HOUSING (TURBINE)
|
1 | 785 |
| 9N-2038 |
CLAMP AS-TURBINE
|
1 | 785 |
| 7W-2297 |
CLAMP AS (COMPRESSOR)
|
1 | 785 |
| 121-5736 |
GASKET (TURBOCHARGER)
|
2 | 786 |
| 2N-2765 |
BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)
|
8 | 786 |
| 2N-2766 |
LOCKNUT (3/8-16-THD)
|
8 | 786 |
| 124-5514 |
COUPLING-EXHAUST
|
2 | 786 |
| 6L-3005 |
CLAMP-BAND (EACH INCLUDES)
|
2 | 786 |
| 8T-0122 |
NUT-FULL (1/4-28-THD)
|
1 | 786 |
| 121-5736 |
GASKET (TURBOCHARGER)
|
2 | 787 |
| 124-5514 |
COUPLING-EXHAUST
|
2 | 787 |
| 450-6710 |
TURBOCHARGER GP
|
2 | 787 |
| 2N-2765 |
BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)
|
8 | 787 |
| 2N-2766 |
LOCKNUT (3/8-16-THD)
|
8 | 787 |
| 6L-3005 |
CLAMP-BAND
|
2 | 787 |
| 7W-2297 |
CLAMP AS (COMPRESSOR)
|
1 | 804 |
| 9N-2038 |
CLAMP AS-TURBINE
|
1 | 804 |
| 6I-0850 |
HOUSING-COMPRESSOR
|
1 | 804 |
| 119-3686 |
HOUSING (TURBINE)
|
1 | 804 |
| 450-1415 |
CARTRIDGE GP-TURBOCHARGER
|
1 | 804 |
