| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 298-3148 |
298-3148
|
1 | 321 |
| 223-3184 |
223-3184
|
1 | 321 |
| 7Y-2853 |
SPACER
|
1 | 322 |
| 122-4120 |
ROD
|
1 | 322 |
| 8T-4192 |
BOLT (L=25mm)
|
15 | 322 |
| 099-4691 |
BOLT
|
2 | 322 |
| 8T-4139 |
BOLT (L=30mm)
|
3 | 322 |
| 223-3172 |
SHEET AS
|
1 | 322 |
| 223-3181 |
SHEET AS
|
1 | 322 |
| 223-3182 |
COVER AS
|
1 | 322 |
| 223-3184 |
SHEET AS
|
1 | 322 |
| 298-3148 |
DOOR AS
|
1 | 322 |
| 307-7791 |
DOOR AS
|
1 | 322 |
| 237-8647 |
HINGE
|
2 | 322 |
| 3B-4618 |
COTTER
|
1 | 322 |
| 7Y-8990 |
SPACER
|
1 | 322 |
| 8T-4121 |
WASHER
|
1 | 322 |
| 5P-1076 |
WASHER
|
20 | 322 |
| 320-5499 |
320-5499
|
1 | 323 |
| 307-7997 |
307-7997
|
1 | 323 |
| 250-5179 |
250-5179
|
1 | 323 |
| 122-4120 |
ROD
|
2 | 324 |
| 8T-4179 |
BOLT (L=20mm)
|
8 | 324 |
| 8T-4192 |
BOLT (L=25mm)
|
29 | 324 |
| 8T-4139 |
BOLT (L=30mm)
|
1 | 324 |
| 223-3150 |
SHEET AS
|
1 | 324 |
| 236-9489 |
LINER
|
2 | 324 |
| 223-3151 |
SHEET AS
|
1 | 324 |
| 223-3153 |
SHEET AS
|
1 | 324 |
| 320-5499 |
SHEET AS
|
1 | 324 |
| 241-2039 |
ANGLE
|
2 | 324 |
| 241-2282 |
SHEET AS
|
1 | 324 |
| 250-5179 |
SHEET AS
|
1 | 324 |
| 289-6591 |
SHEET AS
|
1 | 324 |
| 307-7997 |
SHEET AS
|
1 | 324 |
| 3B-4618 |
COTTER
|
2 | 324 |
| 8T-4121 |
WASHER
|
2 | 324 |
| 5P-1076 |
WASHER
|
38 | 324 |
| 8T-4139 |
BOLT (L=30mm)
|
4 | 326 |
| 141-6518 |
SPACER
|
5 | 326 |
| 208-4156 |
SHIM (T=1.00mm)
|
4 | 326 |
| 208-4157 |
SHIM (T=0.50mm)
|
4 | 326 |
| 244-7789 |
SPACER
|
8 | 326 |
| 244-7820 |
LINER
|
1 | 326 |
| 8T-4183 |
BOLT (L=40mm)
|
2 | 326 |
| 8T-4956 |
BOLT (L=35mm)
|
3 | 326 |
| 5P-1076 |
WASHER
|
4 | 326 |
