| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 4I-3514 |
HOSE AS
|
2 | 478 |
| 7K-1181 |
STRAP
|
5 | 478 |
| 102-1163 |
HOSE AS
|
1 | 478 |
| 237-3190 |
BRACKET
|
1 | 478 |
| 6V-8995 |
UNION
|
1 | 478 |
| 6V-8994 |
UNION
|
2 | 478 |
| 6V-9168 |
NUT
|
2 | 478 |
| 6V-9169 |
NUT
|
1 | 478 |
| 7X-2554 |
BOLT (L=70mm)
|
2 | 478 |
| 9X-8257 |
WASHER
|
2 | 478 |
| 8T-4174 |
BOLT (L=120mm)
|
2 | 478 |
| 9X-8257 |
WASHER
|
2 | 478 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
1 | 478 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
4 | 478 |
