| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 9X-2044 |
SCREW
自攻螺钉 |
7 | 691 |
| 124-3966 |
STOPPER
挡块 |
1 | 691 |
| 124-3974 |
SWITCH
开关 |
1 | 691 |
| 3E-9873 |
SCREW
自攻螺钉 |
1 | 691 |
| 124-3965 |
BRACKET
支架 |
1 | 691 |
| 9X-2042 |
SCREW
自攻螺钉 |
1 | 691 |
| 124-3964 |
BRACKET AS
支架组件 |
1 | 691 |
| 124-3959 |
RAIL (RH)
导轨 |
1 | 691 |
| 6V-5683 |
BOLT (L=16mm)
螺栓 |
5 | 691 |
| 8Y-5745 |
LATCH AS
锁闩组件 |
1 | 691 |
| 4I-1271 |
STOPPER
挡块 |
1 | 691 |
| 4I-3078 |
BRACKET
支架 |
1 | 691 |
| 4I-4224 |
BRACKET AS
支架组件 |
1 | 691 |
| 8T-4137 |
BOLT (L=20mm)
螺栓 |
7 | 691 |
| 8T-4121 |
WASHER
卡箍板 |
7 | 691 |
| 122-9639 |
BRACKET
支架 |
1 | 691 |
| 4I-4280 |
COVER
先导盖 |
1 | 691 |
| 9X-2045 |
SCREW
自攻螺钉 |
6 | 691 |
| 102-7688 |
KNOB
旋钮 |
1 | 691 |
| 7I-1660 |
FILM (INSTRUCTION)
标牌 |
1 | 691 |
| 124-3957 |
CABLE AS
电缆组件 |
1 | 691 |
| 124-3956 |
SPRING AS
气压弹簧组件 |
1 | 691 |
| 122-9635 |
LINER
衬里层 |
1 | 691 |
| 4I-3089 |
CLIP
卡箍 |
4 | 691 |
| 124-3961 |
CLAMP
V 形带箍 |
2 | 691 |
| 100-2881 |
SCREW
自攻螺钉 |
2 | 691 |
| 124-4054 |
GUIDE
导管 |
1 | 691 |
| 124-3960 |
BLOCK
支撑块 |
2 | 691 |
