| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 1T-0936 |
PLUG-PIPE ( )
|
1 | 492 |
| 4B-4158 |
SCREW-DRIVE (3/16X0.25-IN)
改锥口螺钉 (3/16X0.25-IN) |
4 | 492 |
| 6V-3382 |
SEAL-LIP TYPE
唇形油封 |
1 | 492 |
| 8J-2559 |
PLATE-CAUTION
注意标牌 |
1 | 492 |
| 087-4786 |
ADAPTER
接头 |
1 | 492 |
| 096-1519 |
SEAT
座圈 |
1 | 492 |
| 096-5915 |
RETAINER
挡板 |
2 | 492 |
| 108-6503 |
PISTON AS
活塞组件 |
9 | 492 |
| 118-4057 |
SPRING
弹簧 |
9 | 492 |
| 124-1541 |
PIN
销 |
2 | 492 |
| 124-1561 |
SPRING-BRAKE
制动弹簧 |
20 | 492 |
| 137-3708 |
RETAINER
挡板 |
1 | 492 |
| 167-3855 |
SHAFT
轴 |
1 | 492 |
| 167-3857 |
KEY
键 |
1 | 492 |
| 167-3858 |
KEY
键 |
1 | 492 |
| 167-3859 |
PLATE-CAM
凸轮斜盘 |
1 | 492 |
| 167-3862 |
PLATE-RETAINER
挡板 |
1 | 492 |
| 167-3863 |
BALL
球 |
1 | 492 |
| 167-3865 |
PLATE-SEPARATOR
分离器板 |
5 | 492 |
| 167-3866 |
PLATE-FRICTION
摩擦片 |
4 | 492 |
| 167-3867 |
PLATE-PORT
配流口 |
1 | 492 |
| 167-3868 |
PISTON-BRAKE
制动活塞 |
1 | 492 |
| 167-3872 |
SPOOL
滑阀 |
1 | 492 |
| 170-1626 |
RING-BACKUP
支承环 |
1 | 492 |
| 170-1627 |
RING-BACKUP
支承环 |
1 | 492 |
| 173-4063 |
BARREL AS-MOTOR
马达活塞筒组件 |
1 | 492 |
| 173-4066 |
SPACER (63.05X79.8X7-MM THK) ) (63.05X79.8X7-MM
间隔套 厚 |
1 | 492 |
| 175-7436 |
VALVE
阀 |
1 | 492 |
| 175-7887 |
DOWEL
销 |
2 | 492 |
| 180-6769 |
BEARING AS
轴承组件 |
1 | 492 |
| 180-6770 |
BEARING AS
轴承组件 |
1 | 492 |
| 186-5175 |
PLUG
螺塞 |
1 | 492 |
| 189-3189 |
RING-SEAL
密封圈 |
1 | 492 |
| 193-7901 |
BODY AS
阀体组件 |
1 | 492 |
| 196-4987 |
PISTON-ACTUATOR
执行器柱塞 |
1 | 492 |
| 271-6377 |
HEAD AS
缸盖组件 |
1 | 492 |
| 096-5916 |
SEAT
座圈 |
2 | 492 |
| 124-1555 |
PLUG
螺塞 |
4 | 492 |
| 095-1572 |
SEAL-O-RING
O 形密封圈 |
2 | 492 |
| 095-1585 |
SEAL-O-RING
O 形密封圈 |
1 | 492 |
| 095-1596 |
SEAL-O-RING
O 形密封圈 |
1 | 492 |
| 095-1700 |
SEAL-O-RING
O 形密封圈 |
2 | 492 |
| 095-7380 |
SPRING
弹簧 |
1 | 492 |
| 096-0008 |
BOLT-SOCKET HEAD (M16X2X140-MM)
内六角头螺栓 (M16X2X140-MM) |
4 | 492 |
| 096-3978 |
SPRING
弹簧 |
1 | 492 |
| 096-5919 |
RING-BACKUP
支承环 |
2 | 492 |
| 099-7030 |
RING-BACKUP
支承环 |
1 | 492 |
| 170-1616 |
SEAL
密封 |
1 | 492 |
| 2D-6642 |
BALL
球 |
2 | 492 |
| 2M-9780 |
SEAL-O-RING
O 形密封圈 |
1 | 492 |
