| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 239-1610 |
239-1610
|
1 | 394 |
| 259-0922 |
259-0922
|
1 | 394 |
| 126-2075 |
126-2075
|
1 | 394 |
| 188-4140 |
188-4140
|
1 | 394 |
| 4I-5394 |
SENDER
|
1 | 395 |
| 4I-5394 |
SENDER
|
2 | 395 |
| 095-0826 |
LOCKWASHER
|
2 | 395 |
| 119-5162 |
COVER
|
1 | 395 |
| 204-8450 |
SUPPORT AS
|
1 | 395 |
| 213-0677 |
SWITCH AS
|
1 | 395 |
| 102-8802 |
RECEPTACLE KIT
|
1 | 395 |
| 9X-3401 |
PIN
|
2 | 395 |
| 227-0590 |
BREATHER GP
|
1 | 395 |
| 227-0620 |
GAUGE AS
|
1 | 395 |
| 236-3170 |
COVER AS
|
1 | 395 |
| 9X-8256 |
WASHER
|
4 | 395 |
| 259-0922 |
SCREEN GP
|
1 | 395 |
| 207-6403 |
PLUG
|
1 | 395 |
| 207-6404 |
WASHER
|
1 | 395 |
| 095-1608 |
SEAL - O - RING (ID=44.70mm)
|
1 | 395 |
| 095-1735 |
SEAL - O - RING (ID=229.30mm)
|
1 | 395 |
| 112-0065 |
BRACKET
|
1 | 395 |
| 126-2075 |
FILTER GP
|
1 | 395 |
| 158-8987 |
FILTER GP
|
1 | 395 |
| 6V-3965 |
NIPPLE AS
|
1 | 395 |
| 8C-3446 |
VALVE
|
1 | 395 |
| 165-3256 |
PIPE AS
|
1 | 395 |
| 188-4140 |
FILTER GP
|
1 | 395 |
| 2M-0849 |
WASHER
|
2 | 395 |
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
1 | 395 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
1 | 395 |
| 4J-0527 |
SEAL - O - RING (ID=56.74mm)
|
1 | 395 |
| 5C-9553 |
BOLT (L=16mm)
|
4 | 395 |
| 5P-8068 |
SEAL - O - RING (ID=37.47mm)
|
1 | 395 |
| 6D-9157 |
SEAL - O - RING (ID=142.24mm)
|
1 | 395 |
| 6I-0723 |
PLUG
|
1 | 395 |
| 6I-0724 |
ADAPTER
|
1 | 395 |
| 6J-2680 |
SEAL - O - RING (ID=69.44mm)
|
1 | 395 |
| 6V-0852 |
CAP
|
1 | 395 |
| 6V-6707 |
SEAL - O - RING (ID=82.14mm)
|
1 | 395 |
| 8C-3451 |
CAP
|
1 | 395 |
| 8T-0267 |
BOLT (L=12mm)
|
2 | 395 |
| 8T-4121 |
WASHER
|
18 | 395 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 395 |
| 8T-4137 |
BOLT (L=20mm)
|
12 | 395 |
| 8T-4183 |
BOLT (L=40mm)
|
2 | 395 |
| 8T-4195 |
BOLT (L=30mm)
|
4 | 395 |
| 8T-4223 |
WASHER
|
8 | 395 |
| 8T-4224 |
WASHER
|
4 | 395 |
| 8T-4908 |
BOLT (L=25mm)
|
4 | 395 |
