| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 085-6455 |
085-6455
|
1 | 542 |
| 4I-6027 |
HOSE AS (NOM 06, L=3100mm)
|
1 | 543 |
| 4I-8799 |
HOSE AS (NOM 06, L=2900mm)
|
1 | 543 |
| 4I-9521 |
BAND (L1,RED)
|
4 | 543 |
| 4I-9522 |
BAND (L2,YELLOW)
|
4 | 543 |
| 4I-9523 |
BAND (L3,BLUE)
|
4 | 543 |
| 4I-9524 |
BAND (L4,BROWN)
|
4 | 543 |
| 4I-9525 |
BAND (R1,ORANGE)
|
4 | 543 |
| 4I-9526 |
BAND (R2,WHITE)
|
4 | 543 |
| 4I-9527 |
BAND (R3,GREEN)
|
4 | 543 |
| 4I-9528 |
BAND (R4,PURPLE)
|
4 | 543 |
| 5I-8853 |
HOSE AS (NOM 06, L=2750mm)
|
1 | 543 |
| 7K-1181 |
STRAP
|
18 | 543 |
| 7Y-4387 |
HOSE AS (NOM 06, L=2600mm)
|
1 | 543 |
| 085-6455 |
VALVE GP
|
1 | 543 |
| 087-5780 |
HOSE AS (NOM 06, L=2550mm)
|
1 | 543 |
| 102-7685 |
HOSE AS (NOM 06, L=3000mm)
|
2 | 543 |
| 108-7203 |
HOSE AS (NOM 06, L=2600mm)
|
1 | 543 |
| 113-6738 |
HOSE AS (NOM 06, L=3100mm)
|
3 | 543 |
| 113-6741 |
HOSE AS (NOM 06, L=2950mm)
|
1 | 543 |
| 124-1008 |
GUARD
|
1 | 543 |
| 179-7616 |
HOSE AS (NOM 06, L=2500mm)
|
1 | 543 |
| 218-1059 |
HOSE AS (NOM 06, L=2920mm)
|
3 | 543 |
| 255-1671 |
GROMMET
|
1 | 543 |
| 255-1850 |
SUPPORT
|
1 | 543 |
| 115-8645 |
GUARD
|
5 | 543 |
| 6V-9001 |
ELBOW
|
2 | 543 |
| 6V-8724 |
ELBOW
|
9 | 543 |
| 8T-1905 |
ELBOW
|
5 | 543 |
| 8T-4223 |
WASHER
|
6 | 543 |
| 8T-4956 |
BOLT (L=35mm)
|
6 | 543 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
16 | 543 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
16 | 543 |
| 085-6455 |
085-6455
|
1 | 529 |
| 4I-6027 |
HOSE AS (NOM 06, L=3100mm)
|
1 | 530 |
| 4I-8799 |
HOSE AS (NOM 06, L=2900mm)
|
1 | 530 |
| 4I-9521 |
BAND (L1,RED)
|
4 | 530 |
| 4I-9522 |
BAND (L2,YELLOW)
|
4 | 530 |
| 4I-9523 |
BAND (L3,BLUE)
|
4 | 530 |
| 4I-9524 |
BAND (L4,BROWN)
|
4 | 530 |
| 4I-9525 |
BAND (R1,ORANGE)
|
4 | 530 |
| 4I-9526 |
BAND (R2,WHITE)
|
4 | 530 |
| 4I-9527 |
BAND (R3,GREEN)
|
4 | 530 |
| 4I-9528 |
BAND (R4,PURPLE)
|
4 | 530 |
| 5I-8853 |
HOSE AS (NOM 06, L=2750mm)
|
1 | 530 |
| 7K-1181 |
STRAP
|
18 | 530 |
| 7Y-4387 |
HOSE AS (NOM 06, L=2600mm)
|
1 | 530 |
| 085-6455 |
VALVE GP
|
1 | 530 |
| 087-5780 |
HOSE AS (NOM 06, L=2550mm)
|
1 | 530 |
| 102-7685 |
HOSE AS (NOM 06, L=3000mm)
|
2 | 530 |
