| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 5I-7090 |
CHAIN AS
|
1 | 603 |
| 122-9611 |
PEDAL
|
1 | 603 |
| 128-2173 |
PIN
|
1 | 603 |
| 153-8762 |
PEDAL AS
|
1 | 603 |
| 153-8763 |
SUPPORT AS
|
1 | 603 |
| 8T-4224 |
WASHER
|
2 | 603 |
| 095-0735 |
SCREW
|
2 | 603 |
| 7X-2536 |
BOLT (L=14mm)
|
2 | 603 |
| 8T-0114 |
PIN
|
1 | 603 |
| 8T-4121 |
WASHER
|
3 | 603 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 603 |
| 8T-4137 |
BOLT (L=20mm)
|
1 | 603 |
| 5I-7090 |
CHAIN AS
|
1 | 591 |
| 122-9611 |
PEDAL
|
1 | 591 |
| 128-2173 |
PIN
|
1 | 591 |
| 153-8762 |
PEDAL AS
|
1 | 591 |
| 153-8763 |
SUPPORT AS
|
1 | 591 |
| 8T-4224 |
WASHER
|
2 | 591 |
| 095-0735 |
SCREW
|
2 | 591 |
| 7X-2536 |
BOLT (L=14mm)
|
2 | 591 |
| 8T-0114 |
PIN
|
1 | 591 |
| 8T-4121 |
WASHER
|
3 | 591 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 591 |
| 8T-4137 |
BOLT (L=20mm)
|
1 | 591 |
