| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 236-6381 |
236-6381
|
1 | 702 |
| 190-7704 |
190-7704
|
1 | 702 |
| 121-1491 |
121-1491
|
1 | 702 |
| 4T-3148 |
SPRING
|
1 | 703 |
| 116-3600 |
VALVE GP
|
1 | 703 |
| 153-5288 |
SPRING
|
1 | 703 |
| 153-5289 |
GUIDE
|
1 | 703 |
| 153-5290 |
PLUG
|
2 | 703 |
| 153-5291 |
CONNECTOR
|
1 | 703 |
| 153-5292 |
VALVE
|
1 | 703 |
| 153-5293 |
SPRING
|
1 | 703 |
| 153-5294 |
PLUG
|
1 | 703 |
| 153-5295 |
VALVE GP
|
1 | 703 |
| 153-5298 |
SLEEVE
|
1 | 703 |
| 153-5299 |
VALVE
|
1 | 703 |
| 153-5306 |
SPRING
|
1 | 703 |
| 153-5311 |
SPRING
|
1 | 703 |
| 158-8140 |
PLUG
|
1 | 703 |
| 158-8150 |
VALVE GP
|
1 | 703 |
| 158-8206 |
HOUSING
|
1 | 703 |
| 165-9595 |
COVER
|
1 | 703 |
| 190-7704 |
VALVE GP
|
1 | 703 |
| 095-1575 |
SEAL - O - RING (ID=7.80mm)
|
1 | 703 |
| 095-1778 |
RING
|
1 | 703 |
| 103-8173 |
SEAL - O - RING (ID=31.70mm)
|
1 | 703 |
| 121-1491 |
VALVE GP
|
1 | 703 |
| 123-2485 |
PLUG
|
1 | 703 |
| 158-8159 |
HOUSING
|
4 | 703 |
| 2M-9780 |
SEAL - O - RING (ID=19.18mm)
|
1 | 703 |
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
1 | 703 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
1 | 703 |
| 4I-3569 |
RING
|
1 | 703 |
| 4J-5309 |
SEAL - O - RING (ID=9.19mm)
|
1 | 703 |
| 4J-7533 |
SEAL - O - RING (ID=6.07mm)
|
3 | 703 |
| 4K-1388 |
SEAL - O - RING (ID=26.59mm)
|
1 | 703 |
| 6E-2274 |
COVER
|
5 | 703 |
| 6E-3653 |
PLUG
|
1 | 703 |
| 6E-5643 |
VALVE
|
1 | 703 |
| 6E-5644 |
PLUG
|
1 | 703 |
| 6V-5597 |
SEAL - O - RING (ID=40.94mm)
|
4 | 703 |
| 7I-2272 |
BOLT (L=12mm)
|
2 | 703 |
| 7M-8485 |
SEAL - O - RING (ID=29.74mm)
|
3 | 703 |
| 7X-2621 |
BOLT (L=12mm)
|
1 | 703 |
| 7Y-5219 |
SEAL - O - RING (ID=12.37mm)
|
1 | 703 |
| 8T-4121 |
WASHER
|
24 | 703 |
| 8T-4195 |
BOLT (L=30mm)
|
20 | 703 |
| 8T-6685 |
BOLT (L=110mm)
|
4 | 703 |
| 8T-6759 |
PLUG
|
2 | 703 |
| 9S-4180 |
PLUG
|
3 | 703 |
| 236-6381 |
236-6381
|
1 | 704 |
