| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 193-6371 |
193-6371
|
1 | 600 |
| 199-1780 |
SUPPORT AS
|
1 | 601 |
| 199-1948 |
HOSE AS (NOM 06, L=4650mm)
|
1 | 601 |
| 087-4402 |
HOSE AS (NOM 06, L=480mm)
|
2 | 601 |
| 087-6585 |
HOSE AS (NOM 06, L=350mm)
|
2 | 601 |
| 108-7357 |
HOSE AS (NOM 06, L=1950mm)
|
2 | 601 |
| 123-2430 |
VALVE GP
|
1 | 601 |
| 124-1008 |
GUARD
|
1 | 601 |
| 6V-8636 |
CONNECTOR
|
6 | 601 |
| 8T-0075 |
CONNECTOR
|
1 | 601 |
| 6V-9001 |
ELBOW
|
3 | 601 |
| 8C-8988 |
ELBOW
|
1 | 601 |
| 6V-8724 |
ELBOW
|
9 | 601 |
| 9S-4191 |
PLUG
|
3 | 601 |
| 6V-8781 |
TEE
|
1 | 601 |
| 8T-1905 |
ELBOW
|
1 | 601 |
| 107-6631 |
CONNECTOR
|
2 | 601 |
| 108-7516 |
FITTING
|
1 | 601 |
| 167-3466 |
SWITCH AS (PRESSURE)
|
1 | 601 |
| 102-8802 |
RECEPTACLE KIT
|
1 | 601 |
| 9X-3401 |
PIN
|
2 | 601 |
| 179-7578 |
SUPPORT AS
|
1 | 601 |
| 179-7580 |
HOSE AS (NOM 06, L=360mm)
|
1 | 601 |
| 187-6014 |
HOSE AS (NOM 06, L=4000mm)
|
1 | 601 |
| 5I-4076 |
HOSE AS (NOM 06, L=1350mm)
|
1 | 601 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
27 | 601 |
| 7X-0818 |
BOLT (L=45mm)
|
2 | 601 |
| 7Y-4390 |
HOSE AS (NOM 06, L=2400mm)
|
2 | 601 |
| 7Y-7955 |
HOSE AS (NOM 06, L=350mm)
|
1 | 601 |
| 8T-4121 |
WASHER
|
2 | 601 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 601 |
| 8T-4189 |
BOLT (L=20mm)
|
2 | 601 |
| 8T-4224 |
WASHER
|
8 | 601 |
| 8T-6870 |
BOLT (L=70mm)
|
4 | 601 |
| 7K-1181 |
STRAP
|
10 | 601 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
27 | 601 |
