| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 255-5699 |
255-5699
|
1 | 529 |
| 177-2653 |
177-2653
|
1 | 529 |
| 7Y-3731 |
FLANGE
|
1 | 530 |
| 177-2653 |
VALVE GP
|
1 | 530 |
| 193-9994 |
HOSE AS
|
1 | 530 |
| 199-1773 |
ELBOW
|
1 | 530 |
| 212-5148 |
BLOCK
|
1 | 530 |
| 212-5495 |
HOSE AS
|
1 | 530 |
| 260-7872 |
SUPPORT AS
|
1 | 530 |
| 260-7959 |
BRACKET
|
1 | 530 |
| 260-7960 |
SUPPORT
|
1 | 530 |
| 260-8043 |
BLOCK
|
1 | 530 |
| 266-0997 |
HOSE AS
|
1 | 530 |
| 266-1303 |
HOSE AS
|
1 | 530 |
| 099-8232 |
SEAL - O - RING (ID=28.24mm)
|
1 | 530 |
| 101-7404 |
BOLT (L=30mm)
|
4 | 530 |
| 6V-8635 |
CONNECTOR
|
1 | 530 |
| 6V-9007 |
ELBOW
|
1 | 530 |
| 6V-9855 |
ELBOW
|
1 | 530 |
| 9S-4185 |
PLUG
|
1 | 530 |
| 6V-9004 |
ELBOW
|
1 | 530 |
| 1P-3703 |
SEAL
|
2 | 530 |
| 2S-4078 |
SEAL - O - RING (ID=37.47mm)
|
1 | 530 |
| 4J-0522 |
SEAL - O - RING (ID=37.69mm)
|
1 | 530 |
| 5K-9090 |
SEAL - O - RING (OD=27.22mm)
|
2 | 530 |
| 5P-7468 |
CLIP
|
2 | 530 |
| 5P-7469 |
CLIP
|
2 | 530 |
| 6V-0545 |
GROMMET
|
2 | 530 |
| 6V-8400 |
SEAL - O - RING (ID=30.01mm)
|
2 | 530 |
| 8T-4121 |
WASHER
|
2 | 530 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 530 |
| 8T-4139 |
BOLT (L=30mm)
|
3 | 530 |
| 8T-4176 |
BOLT (L=90mm)
|
4 | 530 |
| 8T-4223 |
WASHER
|
15 | 530 |
| 8T-4956 |
BOLT (L=35mm)
|
4 | 530 |
| 8T-5092 |
BOLT (L=150mm)
|
4 | 530 |
| 7M-8485 |
SEAL - O - RING (ID=29.74mm)
|
1 | 530 |
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
2 | 530 |
| 6V-9746 |
SEAL - O - RING (OD=22.50mm)
|
2 | 530 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
1 | 530 |
| 255-5699 |
255-5699
|
1 | 531 |
| 105-3477 |
BOLT (L=45mm)
|
4 | 532 |
| 218-1139 |
BLOCK
|
1 | 532 |
| 255-1936 |
BLOCK
|
1 | 532 |
| 260-7959 |
BRACKET
|
1 | 532 |
| 260-8034 |
SUPPORT
|
1 | 532 |
| 266-1278 |
BLOCK
|
1 | 532 |
| 266-1279 |
FLANGE
|
1 | 532 |
| 275-1439 |
BLOCK
|
1 | 532 |
| 101-7401 |
BOLT (L=20mm)
|
4 | 532 |
