| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 259-7493 |
259-7493
|
1 | 508 |
| 171-0188 |
171-0188
|
1 | 508 |
| 4I-1878 |
HOSE AS (NOM 06, L=1380mm)
|
1 | 509 |
| 8T-6870 |
BOLT (L=70mm)
|
4 | 509 |
| 4I-3941 |
FITTING AS
|
1 | 509 |
| 4I-3988 |
HOSE AS (NOM 06, L=2250mm)
|
1 | 509 |
| 4I-9521 |
BAND (L1,RED)
|
2 | 509 |
| 4I-9522 |
BAND (L2,YELLOW)
|
2 | 509 |
| 4I-9523 |
BAND (L3,BLUE)
|
8 | 509 |
| 4I-9524 |
BAND (L4,BROWN)
|
2 | 509 |
| 4I-9525 |
BAND (R1,ORANGE)
|
2 | 509 |
| 4I-9527 |
BAND (R3,GREEN)
|
8 | 509 |
| 7K-1181 |
STRAP
|
19 | 509 |
| 7Y-4199 |
HOSE AS (NOM 06, L=1800mm)
|
1 | 509 |
| 087-5764 |
HOSE AS (NOM 06, L=1550mm)
|
1 | 509 |
| 087-5772 |
HOSE AS (NOM 06, L=1000mm)
|
1 | 509 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
31 | 509 |
| 111-0988 |
HOSE AS (NOM 06, L=1950mm)
|
1 | 509 |
| 118-9902 |
SPACER
|
1 | 509 |
| 108-7313 |
HOSE AS (NOM 06, L=1900mm)
|
2 | 509 |
| 136-0207 |
STRAP
|
2 | 509 |
| 7X-2459 |
TEE
|
1 | 509 |
| 179-7616 |
HOSE AS (NOM 06, L=2500mm)
|
1 | 509 |
| 212-5419 |
HOSE AS (NOM 06, L=4300mm)
|
1 | 509 |
| 212-5423 |
HOSE AS (NOM 06, L=3450mm)
|
1 | 509 |
| 266-1108 |
SUPPORT AS
|
1 | 509 |
| 266-1133 |
HOSE AS (NOM 06, L=420mm)
|
1 | 509 |
| 278-6470 |
HOSE AS (NOM 06, L=550mm)
|
1 | 509 |
| 266-1139 |
HOSE AS (NOM 06, L=1640mm)
|
1 | 509 |
| 266-1142 |
HOSE AS (NOM 06, L=2400mm)
|
1 | 509 |
| 286-6561 |
SUPPORT AS
|
1 | 509 |
| 124-1008 |
GUARD
|
1 | 509 |
| 6V-8636 |
CONNECTOR
|
2 | 509 |
| 8T-0075 |
CONNECTOR
|
3 | 509 |
| 6V-9001 |
ELBOW
|
1 | 509 |
| 6V-8724 |
ELBOW
|
16 | 509 |
| 6V-9836 |
TEE
|
3 | 509 |
| 8T-1905 |
ELBOW
|
1 | 509 |
| 3E-2310 |
TEE
|
2 | 509 |
| 6V-3965 |
NIPPLE AS
|
2 | 509 |
| 165-9549 |
VALVE GP
|
1 | 509 |
| 309-5769 |
SWITCH AS (PRESSURE)
|
1 | 509 |
| 102-8802 |
RECEPTACLE KIT
|
1 | 509 |
| 9X-3401 |
PIN
|
2 | 509 |
| 171-0188 |
VALVE GP
|
1 | 509 |
| 6V-0852 |
CAP
|
2 | 509 |
| 6V-9829 |
CAP AS
|
1 | 509 |
| 8T-4121 |
WASHER
|
4 | 509 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 509 |
| 8T-4177 |
BOLT (L=90mm)
|
4 | 509 |
