| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 3B-8489 |
FITTING
|
5 | 859 |
| 087-5805 |
PIN
|
2 | 859 |
| 166-1486 |
SHIM (T=2.00mm)
|
2 | 859 |
| 168-2629 |
RING
|
2 | 859 |
| 8T-4132 |
NUT
|
4 | 859 |
| 254-3052 |
PIN
|
1 | 859 |
| 254-3053 |
PIN
|
1 | 859 |
| 264-1622 |
LINK AS
|
1 | 859 |
| 264-1623 |
LINK AS
|
1 | 859 |
| 093-1344 |
SEAL - O - RING (ID=140.00mm)
|
4 | 859 |
| 166-1494 |
SEAL
|
6 | 859 |
| 168-2628 |
PIN
|
2 | 859 |
| 186-5644 |
BOLT (L=150mm)
|
2 | 859 |
| 241-7322 |
LINK AS
|
1 | 859 |
| 240-2912 |
BEARING
|
2 | 859 |
| 244-4360 |
BEARING
|
2 | 859 |
| 3B-8489 |
FITTING
|
5 | 875 |
| 087-5805 |
PIN
|
2 | 875 |
| 166-1486 |
SHIM (T=2.00mm)
|
2 | 875 |
| 168-2629 |
RING
|
2 | 875 |
| 8T-4132 |
NUT
|
4 | 875 |
| 254-3052 |
PIN
|
1 | 875 |
| 254-3053 |
PIN
|
1 | 875 |
| 264-1622 |
LINK AS
|
1 | 875 |
| 264-1623 |
LINK AS
|
1 | 875 |
| 093-1344 |
SEAL - O - RING (ID=140.00mm)
|
4 | 875 |
| 166-1494 |
SEAL
|
6 | 875 |
| 168-2628 |
PIN
|
2 | 875 |
| 186-5644 |
BOLT (L=150mm)
|
2 | 875 |
| 241-7322 |
LINK AS
|
1 | 875 |
| 240-2912 |
BEARING
|
2 | 875 |
| 244-4360 |
BEARING
|
2 | 875 |
