| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 260-7966 |
260-7966
|
1 | 614 |
| 6V-8202 |
BOLT (L=16mm)
|
6 | 615 |
| 085-7083 |
PIN
|
1 | 615 |
| 085-7084 |
BOLT
|
1 | 615 |
| 085-7080 |
LEVER
|
1 | 615 |
| 085-7079 |
GRIP
|
1 | 615 |
| 6V-3938 |
BOLT (L=20mm)
|
4 | 615 |
| 171-0185 |
COVER
|
1 | 615 |
| 085-7081 |
NEEDLE
|
4 | 615 |
| 171-0184 |
SPRING
|
1 | 615 |
| 8T-9533 |
SETSCREW
|
1 | 615 |
| 171-0183 |
COVER
|
1 | 615 |
| 095-1710 |
SEAL - O - RING (ID=79.40mm)
|
2 | 615 |
| 6I-6923 |
SEAL
|
1 | 615 |
| 095-1590 |
SEAL - O - RING (ID=21.80mm)
|
1 | 615 |
| 095-0965 |
PLUG
|
7 | 615 |
| 1F-0425 |
BALL
|
1 | 615 |
| 126-9993 |
SCREW
|
2 | 615 |
| 260-7966 |
260-7966
|
1 | 666 |
| 6V-8202 |
BOLT (L=16mm)
|
6 | 667 |
| 085-7083 |
PIN
|
1 | 667 |
| 085-7084 |
BOLT
|
1 | 667 |
| 085-7080 |
LEVER
|
1 | 667 |
| 085-7079 |
GRIP
|
1 | 667 |
| 6V-3938 |
BOLT (L=20mm)
|
4 | 667 |
| 171-0185 |
COVER
|
1 | 667 |
| 085-7081 |
NEEDLE
|
4 | 667 |
| 171-0184 |
SPRING
|
1 | 667 |
| 8T-9533 |
SETSCREW
|
1 | 667 |
| 171-0183 |
COVER
|
1 | 667 |
| 095-1710 |
SEAL - O - RING (ID=79.40mm)
|
2 | 667 |
| 6I-6923 |
SEAL
|
1 | 667 |
| 095-1590 |
SEAL - O - RING (ID=21.80mm)
|
1 | 667 |
| 095-0965 |
PLUG
|
7 | 667 |
| 1F-0425 |
BALL
|
1 | 667 |
| 126-9993 |
SCREW
|
2 | 667 |
