| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 8T-4136 |
BOLT (L=25mm)
|
2 | 41 |
| 7X-0796 |
LOCKWASHER
|
12 | 41 |
| 8T-4224 |
WASHER
|
4 | 41 |
| 5I-4983 |
STUD (STARTER)
|
2 | 41 |
| 196-7973 |
SENSOR
|
1 | 41 |
| 6V-8231 |
NUT
|
2 | 41 |
| 5I-7661 |
GASKET
|
1 | 41 |
| 8T-7547 |
BOLT (L=30mm)
|
4 | 41 |
| 095-8638 |
WASHER
|
4 | 41 |
| 8T-4195 |
BOLT (L=30mm)
|
8 | 41 |
| 125-2965 |
HOUSING
|
1 | 41 |
| 5I-7607 |
PLUG
|
1 | 41 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 32 |
| 7X-0796 |
LOCKWASHER
|
12 | 32 |
| 8T-4224 |
WASHER
|
4 | 32 |
| 5I-4983 |
STUD (STARTER)
|
2 | 32 |
| 196-7973 |
SENSOR
|
1 | 32 |
| 6V-8231 |
NUT
|
2 | 32 |
| 5I-7661 |
GASKET
|
1 | 32 |
| 8T-7547 |
BOLT (L=30mm)
|
4 | 32 |
| 095-8638 |
WASHER
|
4 | 32 |
| 8T-4195 |
BOLT (L=30mm)
|
8 | 32 |
| 125-2965 |
HOUSING
|
1 | 32 |
| 5I-7607 |
PLUG
|
1 | 32 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 28 |
| 7X-0796 |
LOCKWASHER
|
12 | 28 |
| 8T-4224 |
WASHER
|
4 | 28 |
| 5I-4983 |
STUD (STARTER)
|
2 | 28 |
| 196-7973 |
SENSOR
|
1 | 28 |
| 6V-8231 |
NUT
|
2 | 28 |
| 5I-7661 |
GASKET
|
1 | 28 |
| 8T-7547 |
BOLT (L=30mm)
|
4 | 28 |
| 095-8638 |
WASHER
|
4 | 28 |
| 8T-4195 |
BOLT (L=30mm)
|
8 | 28 |
| 125-2965 |
HOUSING
|
1 | 28 |
| 5I-7607 |
PLUG
|
1 | 28 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 40 |
| 7X-0796 |
LOCKWASHER
|
12 | 40 |
| 8T-4224 |
WASHER
|
4 | 40 |
| 5I-4983 |
STUD (STARTER)
|
2 | 40 |
| 196-7973 |
SENSOR
|
1 | 40 |
| 6V-8231 |
NUT
|
2 | 40 |
| 5I-7661 |
GASKET
|
1 | 40 |
| 8T-7547 |
BOLT (L=30mm)
|
4 | 40 |
| 095-8638 |
WASHER
|
4 | 40 |
| 8T-4195 |
BOLT (L=30mm)
|
8 | 40 |
| 125-2965 |
HOUSING
|
1 | 40 |
| 5I-7607 |
PLUG
|
1 | 40 |
