| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
1 | 895 |
| 6I-6795 |
SPRING
|
1 | 895 |
| 171-0034 |
SEAT
|
1 | 895 |
| 171-0037 |
VALVE
|
1 | 895 |
| 4I-3510 |
SPRING
|
1 | 895 |
| 171-0035 |
HOLDER
|
1 | 895 |
| 171-0036 |
ADJUSTER
|
1 | 895 |
| 095-1579 |
SEAL - O - RING (ID=10.80mm)
|
1 | 895 |
| 6V-8218 |
SEAL - O - RING (ID=32.99mm)
|
1 | 895 |
| 095-1590 |
SEAL - O - RING (ID=21.80mm)
|
1 | 895 |
| 6V-8978 |
SEAL - O - RING (ID=29.82mm)
|
1 | 895 |
| 095-1786 |
RING
|
1 | 895 |
| 095-1587 |
SEAL - O - RING (ID=20.80mm)
|
1 | 895 |
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
1 | 776 |
| 6I-6795 |
SPRING
|
1 | 776 |
| 171-0034 |
SEAT
|
1 | 776 |
| 171-0037 |
VALVE
|
1 | 776 |
| 4I-3510 |
SPRING
|
1 | 776 |
| 171-0035 |
HOLDER
|
1 | 776 |
| 171-0036 |
ADJUSTER
|
1 | 776 |
| 095-1579 |
SEAL - O - RING (ID=10.80mm)
|
1 | 776 |
| 6V-8218 |
SEAL - O - RING (ID=32.99mm)
|
1 | 776 |
| 095-1590 |
SEAL - O - RING (ID=21.80mm)
|
1 | 776 |
| 6V-8978 |
SEAL - O - RING (ID=29.82mm)
|
1 | 776 |
| 095-1786 |
RING
|
1 | 776 |
| 095-1587 |
SEAL - O - RING (ID=20.80mm)
|
1 | 776 |
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
1 | 588 |
| 6I-6795 |
SPRING
|
1 | 588 |
| 171-0034 |
SEAT
|
1 | 588 |
| 171-0037 |
VALVE
|
1 | 588 |
| 4I-3510 |
SPRING
|
1 | 588 |
| 171-0035 |
HOLDER
|
1 | 588 |
| 171-0036 |
ADJUSTER
|
1 | 588 |
| 095-1579 |
SEAL - O - RING (ID=10.80mm)
|
1 | 588 |
| 6V-8218 |
SEAL - O - RING (ID=32.99mm)
|
1 | 588 |
| 095-1590 |
SEAL - O - RING (ID=21.80mm)
|
1 | 588 |
| 6V-8978 |
SEAL - O - RING (ID=29.82mm)
|
1 | 588 |
| 095-1786 |
RING
|
1 | 588 |
| 095-1587 |
SEAL - O - RING (ID=20.80mm)
|
1 | 588 |
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
1 | 764 |
| 6I-6795 |
SPRING
|
1 | 764 |
| 171-0034 |
SEAT
|
1 | 764 |
| 171-0037 |
VALVE
|
1 | 764 |
| 4I-3510 |
SPRING
|
1 | 764 |
| 171-0035 |
HOLDER
|
1 | 764 |
| 171-0036 |
ADJUSTER
|
1 | 764 |
| 095-1579 |
SEAL - O - RING (ID=10.80mm)
|
1 | 764 |
| 6V-8218 |
SEAL - O - RING (ID=32.99mm)
|
1 | 764 |
| 095-1590 |
SEAL - O - RING (ID=21.80mm)
|
1 | 764 |
| 6V-8978 |
SEAL - O - RING (ID=29.82mm)
|
1 | 764 |
