| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 173-7955 |
173-7955
|
1 | 615 |
| 277-0954 |
277-0954
|
1 | 615 |
| 127-6780 |
TUBE AS
|
1 | 616 |
| 142-6582 |
TUBE AS
|
1 | 616 |
| 127-6829 |
HOSE AS
|
1 | 616 |
| 3E-4069 |
CLIP
|
2 | 616 |
| 5P-0201 |
HOSE (150cm)
|
1 | 616 |
| 5P-1010 |
SLEEVE
|
2 | 616 |
| 5P-1130 |
STEM AS (90 )
|
1 | 616 |
| 6V-0746 |
GUARD (206cm)
|
1 | 616 |
| 7X-1452 |
STEM AS (STRAIGHT)
|
1 | 616 |
| 121-1965 |
HOSE AS
|
1 | 616 |
| 2P-6732 |
STEM AS (90 )
|
1 | 616 |
| 2P-6733 |
STEM AS (STRAIGHT)
|
1 | 616 |
| 3E-4062 |
CLIP
|
2 | 616 |
| 5P-0202 |
HOSE (152cm)
|
1 | 616 |
| 5P-0477 |
SLEEVE
|
2 | 616 |
| 6V-0752 |
GUARD (206cm)
|
1 | 616 |
| 277-0954 |
VALVE AS
|
2 | 616 |
| 1P-5767 |
FLANGE
|
4 | 616 |
| 6V-0400 |
FLANGE
|
2 | 616 |
| 7Y-4538 |
CLAMP
|
2 | 616 |
| 173-7916 |
CLAMP
|
2 | 616 |
| 8T-4139 |
BOLT (L=30mm)
|
4 | 616 |
| 8T-4183 |
BOLT (L=40mm)
|
4 | 616 |
| 8T-4184 |
BOLT (L=45mm)
|
4 | 616 |
| 8T-4194 |
BOLT (L=50mm)
|
8 | 616 |
| 8T-4956 |
BOLT (L=35mm)
|
12 | 616 |
| 8T-6685 |
BOLT (L=110mm)
|
4 | 616 |
| 8T-4121 |
WASHER
|
4 | 616 |
| 8T-4223 |
WASHER
|
16 | 616 |
| 1P-3703 |
SEAL
|
2 | 616 |
| 1P-3704 |
SEAL
|
5 | 616 |
| 096-1421 |
CAP AS (MKB1400N)
|
2 | 616 |
| 135-4063 |
FLANGE (MKB1400N)
|
2 | 616 |
| 173-7992 |
173-7992
|
1 | 506 |
| 127-6780 |
TUBE AS
|
1 | 507 |
| 142-6582 |
TUBE AS
|
1 | 507 |
| 127-6829 |
HOSE AS
|
1 | 507 |
| 3E-4069 |
CLIP
|
2 | 507 |
| 5P-0201 |
HOSE (150cm)
|
1 | 507 |
| 5P-1010 |
SLEEVE
|
2 | 507 |
| 5P-1130 |
STEM AS (90 )
|
1 | 507 |
| 6V-0746 |
GUARD (206cm)
|
1 | 507 |
| 7X-1452 |
STEM AS (STRAIGHT)
|
1 | 507 |
| 121-1965 |
HOSE AS
|
1 | 507 |
| 2P-6732 |
STEM AS (90 )
|
1 | 507 |
| 2P-6733 |
STEM AS (STRAIGHT)
|
1 | 507 |
| 3E-4062 |
CLIP
|
2 | 507 |
| 5P-0202 |
HOSE (152cm)
|
1 | 507 |
