| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 191-3225 |
SUPPORT
|
2 | 545 |
| 191-3217 |
SUPPORT AS
|
2 | 545 |
| 8T-4139 |
BOLT (L=30mm)
|
4 | 545 |
| 8T-4223 |
WASHER
|
4 | 545 |
| 9X-8257 |
WASHER
|
4 | 545 |
| 8T-4132 |
NUT
|
4 | 545 |
| 129-7954 |
GUARD
|
1 | 399 |
| 129-7955 |
PLATE AS
|
1 | 399 |
| 129-7957 |
SUPPORT AS
|
2 | 399 |
| 8T-4956 |
BOLT (L=35mm)
|
4 | 399 |
| 8T-4223 |
WASHER
|
8 | 399 |
| 8T-4244 |
NUT
|
12 | 399 |
| 191-3225 |
SUPPORT
|
2 | 400 |
| 191-3217 |
SUPPORT AS
|
2 | 400 |
| 8T-4139 |
BOLT (L=30mm)
|
4 | 400 |
| 8T-4223 |
WASHER
|
4 | 400 |
| 9X-8257 |
WASHER
|
4 | 400 |
| 8T-4132 |
NUT
|
4 | 400 |
| 129-7954 |
GUARD
|
1 | 336 |
| 129-7955 |
PLATE AS
|
1 | 336 |
| 129-7957 |
SUPPORT AS
|
2 | 336 |
| 8T-4956 |
BOLT (L=35mm)
|
4 | 336 |
| 8T-4223 |
WASHER
|
8 | 336 |
| 8T-4244 |
NUT
|
12 | 336 |
| 191-3225 |
SUPPORT
|
2 | 337 |
| 191-3217 |
SUPPORT AS
|
2 | 337 |
| 8T-4139 |
BOLT (L=30mm)
|
4 | 337 |
| 8T-4223 |
WASHER
|
4 | 337 |
| 9X-8257 |
WASHER
|
4 | 337 |
| 8T-4132 |
NUT
|
4 | 337 |
| 191-3225 |
SUPPORT
|
2 | 507 |
| 191-3217 |
SUPPORT AS
|
2 | 507 |
| 8T-4139 |
BOLT (L=30mm)
|
4 | 507 |
| 8T-4223 |
WASHER
|
4 | 507 |
| 9X-8257 |
WASHER
|
4 | 507 |
| 8T-4132 |
NUT
|
4 | 507 |
