| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 202-7133 |
TUBE AS
|
1 | 628 |
| 153-8833 |
TUBE AS
|
1 | 628 |
| 153-8834 |
TUBE AS
|
1 | 628 |
| 153-8867 |
CLIP
|
2 | 628 |
| 096-5766 |
CLAMP
|
1 | 628 |
| 8T-6868 |
BOLT (L=80mm)
|
2 | 628 |
| 8T-4139 |
BOLT (L=30mm)
|
2 | 628 |
| 4I-8888 |
SEAL
|
2 | 628 |
| 8T-4223 |
WASHER
|
4 | 628 |
| 085-8091 |
BOLT (L=55mm)
|
1 | 628 |
| 8T-6466 |
BOLT (L=60mm)
|
1 | 628 |
| 8T-4133 |
NUT
|
1 | 628 |
| 8T-4121 |
WASHER
|
3 | 628 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
2 | 628 |
| 149-1738 |
CLIP
|
2 | 628 |
| 093-1291 |
CLAMP
|
2 | 628 |
| 153-8839 |
PLATE
|
1 | 628 |
| 8T-4185 |
BOLT (L=50mm)
|
1 | 628 |
| 202-7133 |
TUBE AS
|
1 | 630 |
| 226-3063 |
TUBE GP
|
1 | 630 |
| 8T-4185 |
BOLT (L=50mm)
|
1 | 630 |
| 153-8867 |
CLIP
|
2 | 630 |
| 096-5766 |
CLAMP
|
1 | 630 |
| 8T-6868 |
BOLT (L=80mm)
|
2 | 630 |
| 8T-4139 |
BOLT (L=30mm)
|
2 | 630 |
| 7J-9108 |
SEAL - O - RING (OD=19.28mm)
|
1 | 630 |
| 8T-4223 |
WASHER
|
4 | 630 |
| 085-8091 |
BOLT (L=55mm)
|
1 | 630 |
| 8T-6466 |
BOLT (L=60mm)
|
1 | 630 |
| 8T-4133 |
NUT
|
1 | 630 |
| 8T-4121 |
WASHER
|
3 | 630 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
2 | 630 |
| 149-1738 |
CLIP
|
2 | 630 |
| 093-1291 |
CLAMP
|
2 | 630 |
| 153-8839 |
PLATE
|
1 | 630 |
| 153-8835 |
TUBE AS
|
1 | 521 |
| 153-8836 |
TUBE AS
|
1 | 521 |
| 153-8837 |
TUBE AS
|
1 | 521 |
| 153-8867 |
CLIP
|
4 | 521 |
| 096-5766 |
CLAMP
|
3 | 521 |
| 8T-6868 |
BOLT (L=80mm)
|
2 | 521 |
| 8T-4139 |
BOLT (L=30mm)
|
2 | 521 |
| 4I-8888 |
SEAL
|
2 | 521 |
| 8T-4223 |
WASHER
|
4 | 521 |
| 085-8091 |
BOLT (L=55mm)
|
2 | 521 |
| 8T-6466 |
BOLT (L=60mm)
|
1 | 521 |
| 8T-4133 |
NUT
|
1 | 521 |
| 8T-4121 |
WASHER
|
3 | 521 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
2 | 521 |
| 153-8833 |
TUBE AS
|
1 | 523 |
