| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 259-0922 |
259-0922
|
1 | 477 |
| 158-8987 |
158-8987
|
1 | 477 |
| 259-0922 |
SCREEN GP
|
1 | 478 |
| 165-3256 |
PIPE AS
|
1 | 478 |
| 165-3260 |
PIPE AS
|
1 | 478 |
| 168-9697 |
SUPPORT AS
|
1 | 478 |
| 094-3245 |
GAUGE AS
|
1 | 478 |
| 095-1514 |
SEAL - O - RING (ID=9.80mm)
|
4 | 478 |
| 095-1517 |
SEAL - O - RING (ID=13.80mm)
|
4 | 478 |
| 096-4754 |
PIPE
|
1 | 478 |
| 7Y-4754 |
BLOCK
|
2 | 478 |
| 094-3247 |
BOLT (L=36mm)
|
2 | 478 |
| 112-0065 |
BRACKET
|
1 | 478 |
| 126-2075 |
FILTER GP
|
1 | 478 |
| 158-8987 |
FILTER GP
|
1 | 478 |
| 188-4140 |
FILTER GP
|
1 | 478 |
| 2B-0858 |
PLUG
|
1 | 478 |
| 2M-0849 |
WASHER
|
2 | 478 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
1 | 478 |
| 3J-7354 |
SEAL - O - RING (ID=8.92mm)
|
1 | 478 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
2 | 478 |
| 4B-7739 |
PLUG
|
1 | 478 |
| 4I-5394 |
SENDER
|
1 | 478 |
| 4I-5490 |
SCREW
|
2 | 478 |
| 095-0826 |
LOCKWASHER
|
2 | 478 |
| 4J-5267 |
SEAL - O - RING (ID=24.99mm)
|
1 | 478 |
| 6D-9157 |
SEAL - O - RING (ID=142.24mm)
|
1 | 478 |
| 6J-2680 |
SEAL - O - RING (ID=69.44mm)
|
2 | 478 |
| 6V-0852 |
CAP
|
1 | 478 |
| 6V-3965 |
NIPPLE AS
|
1 | 478 |
| 8C-3446 |
VALVE
|
1 | 478 |
| 8C-3451 |
CAP
|
1 | 478 |
| 8H-9819 |
ADAPTER
|
1 | 478 |
| 8T-0267 |
BOLT (L=12mm)
|
2 | 478 |
| 8T-4121 |
WASHER
|
8 | 478 |
| 8T-4136 |
BOLT (L=25mm)
|
4 | 478 |
| 8T-4183 |
BOLT (L=40mm)
|
2 | 478 |
| 8T-4195 |
BOLT (L=30mm)
|
4 | 478 |
| 8T-4223 |
WASHER
|
8 | 478 |
| 8T-4224 |
WASHER
|
4 | 478 |
| 8T-4908 |
BOLT (L=25mm)
|
4 | 478 |
| 8T-4956 |
BOLT (L=35mm)
|
8 | 478 |
| 9S-4185 |
PLUG
|
1 | 478 |
| 7Y-1976 |
HOSE (145cm)
|
1 | 480 |
| 173-5020 |
COVER AS
|
1 | 480 |
| 4I-3743 |
FILLER AS
|
1 | 480 |
| 095-1608 |
SEAL - O - RING (ID=44.70mm)
|
1 | 480 |
| 095-1730 |
SEAL - O - RING (ID=179.30mm)
|
1 | 480 |
| 207-6403 |
PLUG
|
1 | 480 |
| 213-0677 |
SWITCH AS
|
1 | 480 |
