| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 163-7738 |
163-7738
|
1 | 575 |
| 184-9251 |
TUBE AS
|
1 | 576 |
| 6V-9746 |
SEAL - O - RING (OD=22.50mm)
|
11 | 576 |
| 184-9252 |
TUBE AS
|
1 | 576 |
| 5K-9090 |
SEAL - O - RING (OD=27.22mm)
|
3 | 576 |
| 184-9253 |
TUBE AS
|
2 | 576 |
| 184-9254 |
TUBE AS
|
1 | 576 |
| 184-9256 |
TUBE AS
|
1 | 576 |
| 151-1846 |
HOSE AS
|
1 | 576 |
| 5P-0200 |
HOSE (82cm)
|
1 | 576 |
| 5P-1027 |
SLEEVE
|
2 | 576 |
| 7X-1452 |
STEM AS (STRAIGHT)
|
2 | 576 |
| 5I-7290 |
HOSE AS
|
1 | 576 |
| 5P-0201 |
HOSE (81cm)
|
1 | 576 |
| 5P-1010 |
SLEEVE
|
2 | 576 |
| 7X-1452 |
STEM AS (STRAIGHT)
|
2 | 576 |
| 184-9255 |
TUBE AS
|
1 | 576 |
| 4I-1674 |
CLIP
|
6 | 576 |
| 8T-4223 |
WASHER
|
20 | 576 |
| 8T-4139 |
BOLT (L=30mm)
|
20 | 576 |
| 4I-1676 |
CLIP
|
6 | 576 |
| 7Y-4868 |
CLIP
|
8 | 576 |
| 163-7738 |
163-7738
|
1 | 468 |
| 184-9251 |
TUBE AS
|
1 | 469 |
| 6V-9746 |
SEAL - O - RING (OD=22.50mm)
|
11 | 469 |
| 184-9252 |
TUBE AS
|
1 | 469 |
| 5K-9090 |
SEAL - O - RING (OD=27.22mm)
|
3 | 469 |
| 184-9253 |
TUBE AS
|
2 | 469 |
| 184-9254 |
TUBE AS
|
1 | 469 |
| 184-9256 |
TUBE AS
|
1 | 469 |
| 151-1846 |
HOSE AS
|
1 | 469 |
| 5P-0200 |
HOSE (82cm)
|
1 | 469 |
| 5P-1027 |
SLEEVE
|
2 | 469 |
| 7X-1452 |
STEM AS (STRAIGHT)
|
2 | 469 |
| 5I-7290 |
HOSE AS
|
1 | 469 |
| 5P-0201 |
HOSE (81cm)
|
1 | 469 |
| 5P-1010 |
SLEEVE
|
2 | 469 |
| 7X-1452 |
STEM AS (STRAIGHT)
|
2 | 469 |
| 184-9255 |
TUBE AS
|
1 | 469 |
| 4I-1674 |
CLIP
|
6 | 469 |
| 8T-4223 |
WASHER
|
20 | 469 |
| 8T-4139 |
BOLT (L=30mm)
|
20 | 469 |
| 4I-1676 |
CLIP
|
6 | 469 |
| 7Y-4868 |
CLIP
|
8 | 469 |
