| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 184-9210 |
HOSE AS (NOM 06, L=3600mm)
|
1 | 674 |
| 179-7782 |
HOSE AS (NOM 06, L=4100mm)
|
1 | 674 |
| 8T-1905 |
ELBOW
|
1 | 674 |
| 184-9420 |
HOSE AS (NOM 06, L=320mm)
|
1 | 674 |
| 087-4402 |
HOSE AS (NOM 06, L=480mm)
|
1 | 674 |
| 6V-8724 |
ELBOW
|
4 | 674 |
| 6V-8636 |
CONNECTOR
|
2 | 674 |
| 107-6631 |
CONNECTOR
|
1 | 674 |
| 167-3466 |
SWITCH AS (PRESSURE)
|
1 | 674 |
| 102-8802 |
RECEPTACLE KIT
|
1 | 674 |
| 9X-3401 |
PIN
|
2 | 674 |
| 108-7516 |
FITTING
|
1 | 674 |
| 7K-1181 |
STRAP
|
8 | 674 |
| 6V-9850 |
ELBOW
|
1 | 674 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
11 | 674 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
8 | 674 |
| 085-7356 |
FITTING
|
1 | 674 |
| 184-9210 |
HOSE AS (NOM 06, L=3600mm)
|
1 | 569 |
| 179-7782 |
HOSE AS (NOM 06, L=4100mm)
|
1 | 569 |
| 8T-1905 |
ELBOW
|
1 | 569 |
| 184-9420 |
HOSE AS (NOM 06, L=320mm)
|
1 | 569 |
| 087-5766 |
HOSE AS (NOM 06, L=680mm)
|
1 | 569 |
| 6V-8724 |
ELBOW
|
4 | 569 |
| 6V-8636 |
CONNECTOR
|
2 | 569 |
| 107-6631 |
CONNECTOR
|
1 | 569 |
| 167-3466 |
SWITCH AS (PRESSURE)
|
1 | 569 |
| 102-8802 |
RECEPTACLE KIT
|
1 | 569 |
| 9X-3401 |
PIN
|
1 | 569 |
| 107-7516 |
FITTING
|
1 | 569 |
| 7K-1181 |
STRAP
|
8 | 569 |
| 6V-9850 |
ELBOW
|
1 | 569 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
10 | 569 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
8 | 569 |
