| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 153-8765 |
153-8765
|
1 | 728 |
| 201-9350 |
201-9350
|
1 | 728 |
| 158-8159 |
HOUSING
|
1 | 729 |
| 6E-2274 |
COVER
|
1 | 729 |
| 201-9350 |
VALVE GP
|
1 | 729 |
| 9S-8005 |
PLUG
|
1 | 729 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
1 | 729 |
| 8T-4121 |
WASHER
|
4 | 729 |
| 8T-4195 |
BOLT (L=30mm)
|
12 | 729 |
| 6V-5597 |
SEAL - O - RING (ID=40.94mm)
|
2 | 729 |
| 201-9352 |
VALVE GP
|
2 | 729 |
| 6E-5731 |
VALVE
|
1 | 729 |
| 4K-1388 |
SEAL - O - RING (ID=26.59mm)
|
1 | 729 |
| 6E-5730 |
PLUG
|
1 | 729 |
| 7I-1248 |
SPRING
|
1 | 729 |
| 4J-8998 |
SEAL - O - RING (ID=36.09mm)
|
2 | 729 |
| 1P-3702 |
SEAL
|
2 | 729 |
| 109-2667 |
VALVE GP
|
1 | 729 |
| 7Y-8099 |
COVER
|
2 | 729 |
| 1P-3703 |
SEAL
|
1 | 729 |
| 8T-4186 |
BOLT (L=40mm)
|
4 | 729 |
| 7Y-6007 |
COVER
|
1 | 729 |
| 4J-0520 |
SEAL - O - RING (ID=32.92mm)
|
2 | 729 |
| 4B-4158 |
SCREW
|
2 | 729 |
| 153-8765 |
153-8765
|
1 | 542 |
| 201-9350 |
201-9350
|
1 | 542 |
| 158-8159 |
HOUSING
|
1 | 543 |
| 6E-2274 |
COVER
|
1 | 543 |
| 201-9350 |
VALVE GP
|
1 | 543 |
| 9S-8005 |
PLUG
|
1 | 543 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
1 | 543 |
| 8T-4121 |
WASHER
|
4 | 543 |
| 8T-4195 |
BOLT (L=30mm)
|
12 | 543 |
| 6V-5597 |
SEAL - O - RING (ID=40.94mm)
|
2 | 543 |
| 201-9352 |
VALVE GP
|
2 | 543 |
| 6E-5731 |
VALVE
|
1 | 543 |
| 4K-1388 |
SEAL - O - RING (ID=26.59mm)
|
1 | 543 |
| 6E-5730 |
PLUG
|
1 | 543 |
| 7I-1248 |
SPRING
|
1 | 543 |
| 4J-8998 |
SEAL - O - RING (ID=36.09mm)
|
2 | 543 |
| 1P-3702 |
SEAL
|
2 | 543 |
| 109-2667 |
VALVE GP
|
1 | 543 |
| 7Y-8099 |
COVER
|
2 | 543 |
| 1P-3703 |
SEAL
|
1 | 543 |
| 8T-4186 |
BOLT (L=40mm)
|
4 | 543 |
| 7Y-6007 |
COVER
|
1 | 543 |
| 4J-0520 |
SEAL - O - RING (ID=32.92mm)
|
2 | 543 |
| 4B-4158 |
SCREW
|
2 | 543 |
| 153-8765 |
153-8765
|
1 | 712 |
| 109-2667 |
109-2667
|
1 | 712 |
